表 7-146. FLAG_OPEN0 Register Field Descriptions
Bit
7-6
5
Field
Type
Reset
Description
RESERVED
R
0h
Reserved
FLAG_OPENOUTB1
R
0h
Output open-circuit fault flag for OUTB1
0h = Output open-circuit fault is not detected.
1h = Output open-circuit fault is detected.
4
FLAG_OPENOUTB0
R
0h
Output open-circuit fault flag for OUTB0
0h = Output open-circuit fault is not detected.
1h = Output open-circuit fault is detected.
3-2
1
RESERVED
R
R
0h
0h
Reserved
FLAG_OPENOUTA1
Output open-circuit fault flag for OUTA1
0h = Output open-circuit fault is not detected.
1h = Output open-circuit fault is detected.
0
FLAG_OPENOUTA0
R
0h
Output open-circuit fault flag for OUTA0
0h = Output open-circuit fault is not detected.
1h = Output open-circuit fault is detected.
7.6.5.9 FLAG_OPEN1 Register (Offset = A8h) [Reset = 00h]
FLAG_OPEN1 is shown in 图 7-139 and described in 表 7-147.
Return to the Summary Table.
图 7-139. FLAG_OPEN1 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
FLAG_OPENO FLAG_OPENO
RESERVED
R-0h
FLAG_OPENO FLAG_OPENO
UTD1
UTD0
UTC1
UTC0
R-0h
R-0h
R-0h
R-0h
表 7-147. FLAG_OPEN1 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
FLAG_OPENOUTD1
R
0h
Output open-circuit fault flag for OUTD1
0h = Output open-circuit fault is not detected.
1h = Output open-circuit fault is detected.
4
FLAG_OPENOUTD0
R
0h
Output open-circuit fault flag for OUTD0
0h = Output open-circuit fault is not detected.
1h = Output open-circuit fault is detected.
3-2
1
RESERVED
R
R
0h
0h
Reserved
FLAG_OPENOUTC1
Output open-circuit fault flag for OUTC1
0h = Output open-circuit fault is not detected.
1h = Output open-circuit fault is detected.
0
FLAG_OPENOUTC0
R
0h
Output open-circuit fault flag for OUTC0
0h = Output open-circuit fault is not detected.
1h = Output open-circuit fault is detected.
7.6.5.10 FLAG_OPEN2 Register (Offset = A9h) [Reset = 00h]
FLAG_OPEN2 is shown in 图 7-140 and described in 表 7-148.
Return to the Summary Table.
图 7-140. FLAG_OPEN2 Register
7
6
5
4
3
2
1
0
RESERVED
FLAG_OPENO FLAG_OPENO
RESERVED
FLAG_OPENO FLAG_OPENO
UTE1 UTE0
UTF1
UTF0
