表 7-142. FLAG_SLS0 Register Field Descriptions (continued)
Bit
Field
Type
Reset
Description
0
FLAG_SLSOUTA0
R
0h
Single-LED short-circuit fault flag for OUTA0
0h = Single-LED short-circuit fault is not detected.
1h = Single-LED short-circuit fault is detected.
7.6.5.5 FLAG_SLS1 Register (Offset = A4h) [Reset = 00h]
FLAG_SLS1 is shown in 图 7-135 and described in 表 7-143.
Return to the Summary Table.
图 7-135. FLAG_SLS1 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
FLAG_SLSOUT FLAG_SLSOUT
RESERVED
R-0h
FLAG_SLSOUT FLAG_SLSOUT
D1
D0
C1
C0
R-0h
R-0h
R-0h
R-0h
表 7-143. FLAG_SLS1 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
FLAG_SLSOUTD1
R
0h
Single-LED short-circuit fault flag for OUTD1
0h = Single-LED short-circuit fault is not detected.
1h = Single-LED short-circuit fault is detected.
4
FLAG_SLSOUTD0
R
0h
Single-LED short-circuit fault flag for OUTD0
0h = Single-LED short-circuit fault is not detected.
1h = Single-LED short-circuit fault is detected.
3-2
1
RESERVED
R
R
0h
0h
Reserved
FLAG_SLSOUTC1
Single-LED short-circuit fault flag for OUTC1
0h = Single-LED short-circuit fault is not detected.
1h = Single-LED short-circuit fault is detected.
0
FLAG_SLSOUTC0
R
0h
Single-LED short-circuit fault flag for OUTC0
0h = Single-LED short-circuit fault is not detected.
1h = Single-LED short-circuit fault is detected.
7.6.5.6 FLAG_SLS2 Register (Offset = A5h) [Reset = 00h]
FLAG_SLS2 is shown in 图 7-136 and described in 表 7-144.
Return to the Summary Table.
图 7-136. FLAG_SLS2 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
FLAG_SLSOUT FLAG_SLSOUT
RESERVED
R-0h
FLAG_SLSOUT FLAG_SLSOUT
F1
F0
E1
E0
R-0h
R-0h
R-0h
R-0h
表 7-144. FLAG_SLS2 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
FLAG_SLSOUTF1
R
0h
Single-LED short-circuit fault flag for OUTF1
0h = Single-LED short-circuit fault is not detected.
1h = Single-LED short-circuit fault is detected.
