TMS320DM6437
Digital Media Processor
www.ti.com
SPRS345B–NOVEMBER 2006–REVISED MARCH 2007
3.7.3.9 Timer1 Block
This block of 2 pins consists of Timer1, HECC, UART1 Data, and GPIO muxed pins. The
PINMUX1.TIM1BK register field selects the pin functions in the Timer1 Block.
Table 3-33 summarizes the 2 pins in the Timer1 Block, the multiplexed function on each pin, and the
PINMUX configurations to select the corresponding function.
Table 3-33. Timer1 Block Muxed Pins Selection
MULTIPLEXED FUNCTIONS
SIGNAL
NAME
HECC
TIMER1
FUNCTION
UART1
FUNCTION
GPIO
FUNCTION
SELECT
SELECT
SELECT
FUNCTION
SELECT
HECC_RX/
TINP1L/
URXD1/
GP[56]
HECC_RX
TINP1L
URXD1
UTXD1
GP[56]
TIM1BK = 11
TIM1BK = 01
TIM1BK = 10
TIM1BK = 00
HECC_TX/
TOUT1L/
UTXD1/
HECC_TX
TOUT1L
GP[55]
GP[55]
Unlike UART0, UART1 only supports data pins but not flow control pins.
Table 3-34 provides a different view of the Timer1 Block pin muxing, showing the Timer1 Block function
based on PINMUX1.TIM1BK setting. The selection options are also shown pictorially in Figure 3-11.
Table 3-34. Timer1 Block Function Selection
PINMUX1.TIM1BK
BLOCK FUNCTION
GPIO (2) (default)
Timer1
RESULTING PIN FUNCTIONS
GPIO: GP[56:55]
00
01
10
11
Timer1: TINP1L, TOUT1L
UART1: URXD1, UTXD1
HECC: HECC_RX, HECC_TX
UART1 Data
HECC
In addition, the VDD3P3V_PWDN.TIMER1 field determines the power state of the Timer1 Block pins. The
Timer1 Block pins default to powered down and not operational. To use these pins, user must first
program VDD3P3V_PWDN.TIMER1
=
0 to power up the pins. For more details on the
VDD3P3V_PWDN.TIMER1 field, see Section 3.2, Power Considerations.
The Timer1 Block features internal pull up resistors, which matches the UART and HECC inactive polarity.
