TMS320DM6437
Digital Media Processor
www.ti.com
SPRS345B–NOVEMBER 2006–REVISED MARCH 2007
3.7.3.8 Timer0 Block
This block of
2
pins consists of Timer0, McBSP0, McBSP1, and GPIO muxed pins. The
PINMUX1.TIM0BK register field selects the pin functions in the Timer0 Block.
Table 3-31 summarizes the 2 pins in the Timer0 Block, the multiplexed function on each pin, and the
PINMUX configurations to select the corresponding function.
Table 3-31. Timer0 Block Muxed Pins Selection
MULTIPLEXED FUNCTIONS
SIGNAL
NAME
McBSP
Timer0
GPIO
FUNCTION
SELECT
FUNCTION
SELECT
FUNCTION
SELECT
CLKS1/
TINP0L/
GP[98]
CLKS1
TIM0BK = 10
TINP0L
TIM0BK = 01/11
TIM0BK = 01
GP[98]
TIM0BK = 00
CLKS0/
TOUT0L/
GP[97]
CLKS0
TIM0BK = 10/11
TOUT0L
GP[97]
As discussed in Section 3.7.3.2, Peripherals Spanning Multiple Pin Mux Blocks, the McBSP0 pins span
across two Pin Mux Blocks: Serial Port Sub-Block0, and Timer0 Block. For proper McBSP0 operation, the
Serial Port Sub-Block0 must be programmed to select McBSP0 function. The McBSP0 CLKS0 pin in the
Timer0 Block is optional for McBSP0 operation. CLKS0 is only needed if you desire using CLKS0 as an
external clock source to the McBSP0 internal sample rate generator.
Similarly, as discussed in Section 3.7.3.2, Peripherals Spanning Multiple Pin Mux Blocks, the McBSP1
pins span across two Pin Mux Blocks: Serial Port Sub-Block1, and Timer0 Block. For proper McBSP1
operation, the Serial Port Sub-Block1 must be programmed to select McBSP1 function. The McBSP1
CLKS1 pin in the Timer0 Block is optional for McBSP1 operation. CLKS1 is only needed if you desire
using CLKS1 as an external clock source to the McBSP1 internal sample rate generator.
Table 3-32 provides a different view of the Timer0 Block pin muxing, showing the Timer0 Block function
based on PINMUX1.TIM0BK setting. The selection options are also shown pictorially in Figure 3-11.
Table 3-32. Timer0 Block Function Selection
PINMUX1.TIM0BK
BLOCK FUNCTION
GPIO (2) (default)
Timer0
RESULTING PIN FUNCTIONS
GPIO: GP[98:97]
00
01
Timer0: TINP0L, TOUT0L
McBSP0 External Clock Source,
McBSP1 External Clock Source
McBSP0: CLKS0
McBSP1: CLKS1
10
11
McBSP0 External Clock Source,
Timer0 Input
McBSP0: CLKS0
Timer0: TINP0L
In addition, the VDD3P3V_PWDN.TIMER0 field determines the power state of the Timer0 Block pins. The
Timer0 Block pins default to powered down and not operational. To use these pins, user must first
program VDD3P3V_PWDN.TIMER0
=
0 to power up the pins. For more details on the
VDD3P3V_PWDN.TIMER0 field, see Section 3.2, Power Considerations.
