TMS320C6678
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS691D—April 2013
www.ti.com
Table 3-8
LRESETNMI PIN Status Clear Register (LRSTNMIPINSTAT_CLR) Field Descriptions
Bit
Field
Description
31-16 Reserved
Reserved
15
14
13
12
11
10
9
NMI7
NMI6
NMI5
NMI4
NMI3
NMI2
NMI1
NMI0
LR7
CorePac7 in NMI clear
CorePac6 in NMI clear
CorePac5 in NMI clear
CorePac4 in NMI clear
CorePac3 in NMI clear
CorePac2 in NMI clear
CorePac1 in NMI clear
CorePac0 in NMI clear
CorePac7 in local reset clear
CorePac6 in local reset clear
CorePac5 in local reset clear
CorePac4 in local reset clear
CorePac3 in local reset clear
CorePac2 in local reset clear
CorePac1 in local reset clear
CorePac0 in local reset clear
8
7
6
LR6
5
LR5
4
LR4
3
LR3
2
LR2
1
LR1
0
LR0
End of Table 3-8
