3.3.8 Reset Status (RESET_STAT) Register
The reset status register (RESET_STAT) captures the status of Local reset (LRx) for each of the cores and also the
global device reset (GR). Software can use this information to take different device initialization steps, if desired.
•
In case of Local reset: The LRx bits are written as 1 and GR bit is written as 0 only when the CorePac receives
an local reset without receiving a global reset.
•
In case of Global reset: The LRx bits are written as 0 and GR bit is written as 1 only when a global reset is
asserted.
The Reset Status Register is shown in Figure 3-7 and described in Table 3-9.
Figure 3-7
Reset Status Register (RESET_STAT)
31
GR
30
8
7
6
5
4
3
2
1
0
Reserved
LR7
R,+0
LR6
R,+0
LR5
R,+0
LR4
R,+0
LR3
R,+0
LR2
R,+0
LR1
R,+0
LR0
R,+0
R, +1
R, + 000 0000 0000 0000 0000 0000
Legend: R = Read only; -n = value after reset
Table 3-9
Reset Status Register (RESET_STAT) Field Descriptions
Description
Bit
Field
GR
31
Global reset status
0 = Device has not received a global reset.
1 = Device received a global reset.
30-8
7
Reserved
LR7
Reserved
CorePac7 reset status
0 = CorePac7 has not received a local reset.
1 = CorePac7 received a local reset.
6
5
4
3
2
1
0
LR6
LR5
LR4
LR3
LR2
LR1
LR0
CorePac6 reset status
0 = CorePac6 has not received a local reset.
1 = CorePac6 received a local reset.
CorePac5 reset status
0 = CorePac5 has not received a local reset.
1 = CorePac5 received a local reset.
CorePac4 reset status
0 = CorePac4 has not received a local reset.
1 = CorePac4 received a local reset.
CorePac3 reset status
0 = CorePac3 has not received a local reset.
1 = CorePac3 received a local reset.
CorePac2 reset status
0 = CorePac2 has not received a local reset.
1 = CorePac2 received a local reset.
CorePac1 reset status
0 = CorePac1 has not received a local reset.
1 = CorePac1 received a local reset.
CorePac0 reset status
0 = CorePac0 has not received a local reset.
1 = CorePac0 received a local reset.
End of Table 3-9
