3.3.9 Reset Status Clear (RESET_STAT_CLR) Register
The RESET_STAT bits can be cleared by writing 1 to the corresponding bit in the RESET_STAT_CLR register. The
Reset Status Clear Register is shown in Figure 3-8 and described in Table 3-10.
Figure 3-8
Reset Status Clear Register (RESET_STAT_CLR)
31
GR
30
8
7
6
5
4
3
2
1
0
Reserved
LR7
LR6
LR5
LR4
LR3
LR2
LR1
LR0
RW, +0
R, + 000 0000 0000 0000 0000 0000
RW,+0
RW,+0
RW,+0
RW,+0
RW,+0
RW,+0
RW,+0
RW,+0
Legend: R = Read only; RW = Read/Write; -n = value after reset
Table 3-10
Reset Status Clear Register (RESET_STAT_CLR) Field Descriptions
Description
Bit
Field
31
GR
Global reset clear bit
0 = Writing a 0 has no effect.
1 = Writing a 1 to the GR bit clears the corresponding bit in the RESET_STAT register.
30-8
7
Reserved
LR7
Reserved.
CorePac7 reset clear bit
0 = Writing a 0 has no effect.
1 = Writing a 1 to the LR3 bit clears the corresponding bit in the RESET_STAT register.
6
5
4
3
2
1
0
LR6
LR5
LR4
LR3
LR2
LR1
LR0
CorePac6 reset clear bit
0 = Writing a 0 has no effect.
1 = Writing a 1 to the LR3 bit clears the corresponding bit in the RESET_STAT register.
CorePac5 reset clear bit
0 = Writing a 0 has no effect.
1 = Writing a 1 to the LR3 bit clears the corresponding bit in the RESET_STAT register.
CorePac4 reset clear bit
0 = Writing a 0 has no effect.
1 = Writing a 1 to the LR3 bit clears the corresponding bit in the RESET_STAT register.
CorePac3 reset clear bit
0 = Writing a 0 has no effect.
1 = Writing a 1 to the LR3 bit clears the corresponding bit in the RESET_STAT register.
CorePac2 reset clear bit
0 = Writing a 0 has no effect.
1 = Writing a 1 to the LR2 bit clears the corresponding bit in the RESET_STAT register.
CorePac1 reset clear bit
0 = Writing a 0 has no effect.
1 = Writing a 1 to the LR1 bit clears the corresponding bit in the RESET_STAT register.
CorePac0 reset clear bit
0 = Writing a 0 has no effect.
1 = Writing a 1 to the LR0 bit clears the corresponding bit in the RESET_STAT register.
End of Table 3-10
