TMS320C6678
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS691D—April 2013
www.ti.com
Table 7-38
TMS320C6678 System Event Mapping — C66x CorePac Primary Interrupts (Part 3 of 4)
Event Number
83
Interrupt Event
Description
GPINT9
Local GPIO interrupt
84
GPINT10
Local GPIO interrupt
85
GPINT11
Local GPIO interrupt
86
GPINT12
Local GPIO interrupt
87
GPINT13
Local GPIO interrupt
88
GPINT14
Local GPIO interrupt
89
GPINT15
Local GPIO interrupt
90
GPINTn (10)
Local GPIO interrupt
91
IPC_LOCAL
Inter DSP interrupt from IPCGRn
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Dropped CPU interrupt event
Invalid IDMA parameters
92
CIC0_OUT(4+8*n) (7) Or CIC1_OUT(4+8*(n-4)) (7)
CIC0_OUT(5+8*n) (7) Or CIC1_OUT(5+8*(n-4)) (7)
CIC0_OUT(6+8*n) (7) Or CIC1_OUT(6+8*(n-4)) (7)
CIC0_OUT(7+8*n) (7) Or CIC1_OUT(7+8*(n-4)) (7)
INTERR
93
94
95
96
97
EMC_IDMAERR
98
Reserved
99
Reserved
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
EFIINTA
EFI Interrupt from side A
EFI Interrupt from side B
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
VbusM error event
EFIINTB
CIC0_OUT0 or CIC1_OUT0
CIC0_OUT1 or CIC1_OUT1
CIC0_OUT8 or CIC1_OUT8
CIC0_OUT9 or CIC1_OUT9
CIC0_OUT16 or CIC1_OUT16
CIC0_OUT17 or CIC1_OUT17
CIC0_OUT24 or CIC1_OUT24
CIC0_OUT25 or CIC1_OUT25
MDMAERREVT
Reserved
EDMA3CC0_EDMACC_AETEVT
PMC_ED
EDMA3CC0 AET event
Single bit error detected during DMA read
EDMA3CC1 AET Event
EDMA3CC1_EDMACC_AETEVT
EDMA3CC2_EDMACC_AETEVT
UMC_ED1
EDMA3CC2 AET Event
Corrected bit error detected
UMC_ED2
Uncorrected bit error detected
PDC_INT
Power down sleep interrupt
SYS_CMPA
SYS CPU memory protection fault event
PMC CPU memory protection fault event
PMC DMA memory protection fault event
DMC CPU memory protection fault event
DMC DMA memory protection fault event
UMC CPU memory protection fault event
UMC DMA memory protection fault event
PMC_CMPA
PMC_DMPA
DMC_CMPA
DMC_DMPA
UMC_CMPA
UMC_DMPA
