TMS320C6678
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS691D—April 2013
www.ti.com
Table 7-24
Main PLL Control Register 0 (MAINPLLCTL0) Field Descriptions (Part 2 of 2)
Bit
Field
Description
11-6
5-0
Reserved
PLLD
Reserved
A 6-bit bus that selects the values for the reference divider
End of Table 7-24
Figure 7-18
Main PLL Control Register 1 (MAINPLLCTL1)
31
7
6
5
4
3
0
Reserved
ENSAT
RW-0
Reserved
RW-00
BWADJ[11:8]
RW-0000
RW-0000000000000000000000000
Legend: RW = Read/Write; -n = value after reset
Table 7-25
Main PLL Control Register 1 (MAINPLLCTL1) Field Descriptions
Description
Bit
31-7
6
Field
Reserved
Reserved
ENSAT
Needs to be set to 1 for proper operation of PLL
Reserved
5-4
3-0
Reserved
BWADJ[11:8]
BWADJ[11:8] and BWADJ[7:0] are located in MAINPLLCTL0 and MAINPLLCTL1 registers. The combination (BWADJ[11:0])
should be programmed to a value equal to half of PLLM[12:0] value (round down if PLLM has an odd value). Example:
PLLM=15, then BWADJ=7
End of Table 7-25
Note—PLLM[5:0] bits of the multiplier is controlled by the PLLM register inside the PLL Controller
and PLLM[12:6] bits are controlled by the MAINPLLCTL0 chip-level register. The MAINPLLCTL0 register
PLLM[12:6] bits should be written just before writing to the PLLM register PLLM[5:0] bits in the controller
to have the complete 13 bit value latched when the GO operation is initiated in the PLL controller. See the
Phase Locked Loop (PLL) for KeyStone Devices User Guide in ‘‘Related Documentation from Texas
Instruments’’ on page 73 for the recommended programming sequence. Output divide ratio and Bypass
enable/disable of the Main PLL is controlled by the SECCTL register in the PLL Controller. See the
7.5.2.1 ‘‘PLL Secondary Control Register (SECCTL)’’ for more details.
7.5.4 Main PLL and PLL Controller Initialization Sequence
See the Phase Locked Loop (PLL) for KeyStone Devices User Guide in ‘‘Related Documentation from Texas
Instruments’’ on page 73 for details on the initialization sequence for Main PLL and PLL Controller.
7.5.5 Main PLL Controller/SRIO/HyperLink/PCIe Clock Input Electrical Data/Timing
Table 7-26
Main PLL Controller/SRIO/HyperLink/PCIe Clock Input Timing Requirements (1) (Part 1 of 3)
(see Figure 7-19 and Figure 7-20)
No.
Min
Max Unit
CORECLK[P:N]
1
1
3
2
2
tc(CORCLKN)
tc(CORECLKP)
tw(CORECLKN)
tw(CORECLKN)
tw(CORECLKP)
Cycle time _ CORECLKN cycle time
Cycle time _ CORECLKP cycle time
Pulse width _ CORECLKN high
Pulse width _ CORECLKN low
Pulse width _ CORECLKP high
3.2
3.2
25
25
ns
ns
ns
ns
ns
0.45*tc(CORECLKN)
0.45*tc(CORECLKN)
0.45*tc(CORECLKP)
0.55*tc(CORECLKN)
0.55*tc(CORECLKN)
0.55*tc(CORECLKP)
Copyright 2013 Texas Instruments Incorporated
Peripheral Information and Electrical Specifications 149
