TMS320C6672
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS708C—February 2012
www.ti.com
Table 7-39
CIC0 Event Inputs (Secondary Interrupts for C66x CorePacs) (Part 2 of 4)
Input Event# on CIC
System Interrupt
EDMA3CC0 CCINT3
EDMA3CC0 CCINT4
EDMA3CC0 CCINT5
EDMA3CC0 CCINT6
EDMA3CC0 CCINT7
Reserved
Description
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
81
82
84
EDMA3CC0 individual completion interrupt
EDMA3CC0 individual completion interrupt
EDMA3CC0 individual completion interrupt
EDMA3CC0 individual completion interrupt
EDMA3CC0 individual completion interrupt
QM_INT_PASS_TXQ_PEND_12
PCIEXpress_ERR_INT
PCIEXpress_PM_INT
PCIEXpress_Legacy_INTA
PCIEXpress_Legacy_INTB
PCIEXpress_Legacy_INTC
PCIEXpress_Legacy_INTD
SPIINT0
Queue manager pend event
Protocol error interrupt
Power management interrupt
Legacy interrupt mode
Legacy interrupt mode
Legacy interrupt mode
Legacy interrupt mode
SPI interrupt0
SPIINT1
SPI interrupt1
SPIXEVT
Transmit event
SPIREVT
Receive event
I2C interrupt
I2C receive event
I2C transmit event
I2CINT
I2CREVT
I2CXEVT
Reserved
Reserved
TETBHFULLINT
TETB is half full
TETBFULLINT
TETB is full
TETBACQINT
Acquisition has been completed
Overflow condition occur
TETBOVFLINT
TETBUNFLINT
Underflow condition occur
MDIO_LINK_INTR0
MDIO_LINK_INTR1
MDIO_USER_INTR0
MDIO_USER_INTR1
MISC_INTR
Network coprocessor MDIO interrupt
Network coprocessor MDIO interrupt
Network coprocessor MDIO interrupt
Network coprocessor MDIO interrupt
Network coprocessor MISC interrupt
Tracer sliding time window interrupt for individual core
Tracer sliding time window interrupt for individual core
TRACER_CORE_0_INTD
TRACER_CORE_1_INTD
Reserved
Reserved
TRACER_DDR_INTD
TRACER_MSMC_0_INTD
TRACER_MSMC_1_INTD
TRACER_MSMC_2_INTD
TRACER_MSMC_3_INTD
TRACER_CFG_INTD
TRACER_QM_SS_CFG_INTD
TRACER_QM_SS_DMA_INTD
Tracer sliding time window interrupt for DDR3 EMIF1
Tracer sliding time window interrupt for MSMC SRAM bank0
Tracer sliding time window interrupt for MSMC SRAM bank1
Tracer sliding time window interrupt for MSMC SRAM bank2
Tracer sliding time window interrupt for MSMC SRAM bank3
Tracer sliding time window interrupt for CFG0 SCR
Tracer sliding time window interrupt for QM_SS CFG
Tracer sliding time window interrupt for QM_SS slave
162
