Table 7-38
TMS320C6672 System Event Mapping — C66x CorePac Primary Interrupts (Part 3 of 4)
Event Number
Interrupt Event
QM_INT_LOW_13
QM_INT_LOW_14
QM_INT_LOW_15
QM_INT_HIGH_n (7)
QM_INT_HIGH_(n+8) (7)
QM_INT_HIGH_(n+16) (7)
QM_INT_HIGH_(n+24) (7)
TSIP0_RFSINT[n] (5)
TSIP0_RSFINT[n] (5)
TSIP0_XFSINT[n] (5)
TSIP0_XSFINT[n] (5)
TSIP1_RFSINT[n] (5)
TSIP1_RSFINT[n] (5)
TSIP1_XFSINT[n] (5)
TSIP1_XSFINT[n] (5)
Reserved
Description
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
QM Interrupt for 416~447 Queues
QM Interrupt for 448~479 Queues
QM Interrupt for 480~511 Queues
QM Interrupt for Queue 704+n8
QM Interrupt for Queue 712+n8
QM Interrupt for Queue 720+n8
QM Interrupt for Queue 728+n8
TSIP0 receive frame sync interrupt
TSIP0 receive super frame interrupt
TSIP0 transmit frame sync interrupt
TSIP0 transmit super frame interrupt
TSIP1 receive frame sync interrupt
TSIP1 receive super frame interrupt
TSIP1 transmit frame sync interrupt
TSIP1 transmit super frame interrupt
Reserved
CIC0_OUT(2+8*n)
CIC0_OUT(3+8*n)
TINTLn (8)
Interrupt Controller Output
Interrupt Controller Output
Local timer interrupt low
Local timer interrupt high
Timer interrupt low
Timer interrupt high
Timer interrupt low
Timer interrupt high
Timer interrupt low
Timer interrupt high
Timer interrupt low
Timer interrupt high
Timer interrupt low
Timer interrupt high
Timer interrupt low
Timer interrupt high
Timer interrupt low
Timer interrupt high
Timer interrupt low
Timer interrupt high
Local GPIO interrupt
Local GPIO interrupt
Local GPIO interrupt
Local GPIO interrupt
Local GPIO interrupt
Local GPIO interrupt
Local GPIO interrupt
TINTHn (8)
TINT2L
TINT2H
TINT3L
TINT3H
TINT4L
TINT4H
TINT5L
TINT5H
TINT6L
TINT6H
TINT7L
TINT7H
TINT8L
TINT8H
TINT9L
TINT9H
GPINT8
GPINT9
GPINT10
GPINT11
GPINT12
GPINT13
GPINT14
