7.8.4 EDMA3 Channel Synchronization Events
The EDMA3 supports up to 16 DMA channels for EDMA3CC0, 64 each for EDMA3CC1 and EDMA3CC2 that can
be used to service system peripherals and to move data between system memories. DMA channels can be triggered
by synchronization events generated by system peripherals. The following tables lists the source of the
synchronization event associated with each of the EDMA EDMA3CC DMA channels. On the C6672, the association
of each synchronization event and DMA channel is fixed and cannot be reprogrammed.
For more detailed information on the EDMA3 module and how EDMA3 events are enabled, captured, processed,
prioritized, linked, chained, and cleared, etc., see the Enhanced Direct Memory Access 3 (EDMA3) for KeyStone
Devices User Guide in ‘‘Related Documentation from Texas Instruments’’ on page 69.
Table 7-35
EDMA3CC0 Events for C6672
Event Number
Event
Event Description
0
TINT2L
Timer interrupt low
1
TINT2H
Timer interrupt high
2
TINT3L
Timer interrupt low
3
TINT3H
Timer interrupt high
4
TINT4L
Timer interrupt low
5
TINT4H
Timer interrupt high
6
TINT5L
Timer interrupt low
7
TINT5H
Timer interrupt high
8
CIC3_OUT0
CIC3_OUT1
CIC3_OUT2
CIC3_OUT3
CIC3_OUT4
CIC3_OUT5
CIC3_OUT6
CIC3_OUT7
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
Interrupt Controller output
9
10
11
12
13
14
15
End of Table 7-35
Table 7-36
EDMA3CC1 Events for C6672 (Part 1 of 3)
Event Number
Event
Event Description
SPI interrupt
0
SPIINT0
SPIINT1
SPIXEVT
SPIREVT
I2CREVT
I2CXEVT
GPINT0
GPINT1
GPINT2
GPINT3
GPINT4
GPINT5
GPINT6
GPINT7
1
SPI interrupt
2
Transmit event
Receive event
I2C receive event
I2C transmit event
GPIO interrupt
GPIO interrupt
GPIO interrupt
GPIO interrupt
GPIO interrupt
GPIO interrupt
GPIO interrupt
GPIO interrupt
3
4
5
6
7
8
9
10
11
12
13
