For the range of memory addresses that include EDMA3 channel controller (EDMA3CC) control registers and
EDMA3 transfer controller (EDMA3TC) control register see Section Table 2-2‘‘Memory Map Summary’’ on
page 21. For memory offsets and other details on EDMA3CC and EDMA3TC control registers entries, see the
Enhanced Direct Memory Access 3 (EDMA3) for KeyStone Devices User Guide in ‘‘Related Documentation from
Texas Instruments’’ on page 69.
7.8.2 EDMA3 Channel Controller Configuration
Table 7-33 provides the configuration for each of the EDMA3 channel controllers present on the device.
Table 7-33
Description
EDMA3 Channel Controller Configuration
EDMA3 CC0 EDMA3 CC1 EDMA3 CC2
Number of DMA channels in Channel Controller
Number of QDMA channels
16
8
64
8
64
8
Number of interrupt channels
Number of PaRAM set entries
16
128
2
64
512
4
64
512
4
Number of event queues
Number of Transfer Controllers
Memory Protection Existence
Number of Memory Protection and Shadow Regions
End of Table 7-33
2
4
4
Yes
8
Yes
8
Yes
8
7.8.3 EDMA3 Transfer Controller Configuration
Each transfer controller on a device is designed differently based on considerations like performance requirements,
system topology (like main TeraNet bus width, external memory bus width), etc. The parameters that determine the
transfer controller configurations are:
•
FIFOSIZE: Determines the size in bytes for the Data FIFO that is the temporary buffer for the in-flight data.
The data FIFO is where the read return data read by the TC read controller from the source endpoint is stored
and subsequently written out to the destination endpoint by the TC write controller.
•
•
•
BUSWIDTH: The width of the read and write data buses in bytes, for the TC read and write controller,
respectively. This is typically equal to the bus width of the main TeraNet interface.
Default Burst Size (DBS): The DBS is the maximum number of bytes per read/write command issued by a
transfer controller.
DSTREGDEPTH: This determines the number of Destination FIFO register set. The number of Destination
FIFO register set for a transfer controller determines the maximum number of outstanding transfer requests.
All four parameters listed above are fixed by the design of the device.
Table 7-34 provides the configuration for each of the EDMA3 transfer controllers present on the device.
Table 7-34
Parameter
EDMA3 Transfer Controller Configuration
EDMA3 CC0
TC1
EDMA3 CC1
TC2
EDMA3 CC2
TC2
TC0
TC0
TC1
TC3
TC0
TC1
TC3
FIFOSIZE
1024 bytes 1024 bytes 1024 bytes 512 bytes 1024 bytes 512 bytes 1024 bytes 512 bytes 512 bytes 1024 bytes
BUSWIDTH
32 bytes
32 bytes
4 entries
128 bytes
16 bytes
4 entries
128 bytes
16 bytes
4 entries
64 bytes
16 bytes
4 entries
128 bytes
16 bytes
4 entries
64 bytes
16 bytes
4 entries
128 bytes
16 bytes
4 entries
64 bytes
16 bytes
4 entries
64 bytes
16 bytes
4 entries
128 bytes
DSTREGDEPTH 4 entries
DBS 128 bytes
End of Table 7-34
