TMS320C6672
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS708C—February 2012
www.ti.com
7.4.4 Local Reset
The local reset can be used to reset a particular CorePac without resetting any other chip components.
Local reset is initiated by the following (for more details see the Phase Locked Loop (PLL) Controller for KeyStone
Devices User Guide in ‘‘Related Documentation from Texas Instruments’’ on page 69:
•
LRESET pin
•
Watchdog timer should cause one of the below based on the setting of the CORESEL[2:0] and RSTCFG
register in the PLL controller. See ‘‘Reset Configuration Register (RSTCFG)’’ on page 140 and ‘‘CIC Registers’’
on page 170:
–
–
–
–
Local Reset
NMI
NMI followed by a time delay and then a local reset for the CorePac selected
Hard Reset by requesting reset via PLLCTL
•
LPSC MMRs (memory-mapped registers)
7.4.5 Reset Priority
If any of the above reset sources occur simultaneously, the PLLCTL processes only the highest priority reset request.
The reset request priorities are as follows (high to low):
•
•
Power-on reset
Hard/Soft reset
7.4.6 Reset Controller Register
The reset controller register are part of the PLLCTL MMRs. All C6672 device-specific MMRs are covered in Section
7.5.3 ‘‘Main PLL Control Register’’ on page 141. For more details on these registers and how to program them, see
the Phase Locked Loop (PLL) Controller for KeyStone Devices User Guide in ‘‘Related Documentation from Texas
Instruments’’ on page 69.
Copyright 2012 Texas Instruments Incorporated
Peripheral Information and Electrical Specifications 129
