TYPICAL CHARACTERISTICS (continued)
At VCC = 3.3 V and TA = +25°C, unless otherwise noted.
CONSTANT CURRENT OUTPUT
VOLTAGE WAVEFORM
CH1-BLANK
(20 ns)
CH1 (2 V/div)
CH2-OUT0
(BLANK = 20 ns)
CH2 (2 V/div)
CH3 (2 V/div)
CH3-OUT15
(BLANK = 20 ns)
IOLC = 35 mA
TA = +25°C
RL = 130 W
CL = 15 pF
VLED = 5.5 V
Time (12.5 ns/div)
Figure 16.
