4.6.2.3 Special Clock Source Selection Scheme for VCLKA4_DIVR_EMAC
Some applications may need to use both the of Ethernet interfaces. The MII interface requires
VCLKA4_DIVR_EMAC to be 25MHz and the RMII requires VCLKA4_DIVR_EAMC to be 50MHz.
These different frequencies are supported by adding special dedicated clock source selection options for
the VCLKA4_DIVR_EMAC clock domain. This logic is shown in .
0
1
3
4
VCLKA4_S (left open)
5
6
7
VCLK
/DIVR
VCLKA4_DIVR_EMAC
PLL2 post_ODCLK/8
(to EMAC)
PLL2 post_ODCLK/16
VCLKA4_SRC
Figure 4-8. VCLKA4_DIVR Source Selection Options
The PLL2 post_ODCLK is brought out as a separate output from the PLL wrapper module. There are two
additional dividers implemented at the device-level to divide this PLL2 post_ODCLK by 8 and by 16.
As shown in , the VCLKA4_SRC configured via the system module VCLKACON1 control register is used
to determine the clock source for the VCLKA4_S and VCLKA4_DIVR. An additional multiplexor is
implemented to select between the VCLKA4_DIVR and the two additional clock sources – PLL2
post_ODCLK/8 and post_ODCLK/16.
The selection is done as shown in the following table.
Table 4-14. VCLKA4_DIVR_EMAC Clock Source
Selection
VCLKA4_SRC from
VCLKACON1[19–16]
Clock Source for
VCLKA4_DIVR_EMAC
0x0
0x1
0x2
0x3
0x4
0x5
0x6
0x7
OSCIN / VCLKA4R
PLL1CLK / VCLKA4R
Reserved
EXTCLKIN1 / VCLKA4R
LF LPO / VCLKA4R
HF LPO / VCLKA4R
PLL2CLK / VCLKA4R
EXTCLKIN2 / VCLKA4R
