RM46L450
RM46L850
SPNS184 –SEPTEMBER 2012
www.ti.com
4.6.1.4 External Clock Inputs
The device supports up to two external clock inputs. This clock input must be a square wave input. The
electrical and timing requirements for these clock inputs are specified below.
Table 4-12. External Clock Timing and Electrical Specifications
Parameter
fEXTCLKx
Description
External clock input frequency
EXTCLK high-pulse duration
EXTCLK low-pulse duration
Low-level input voltage
Min
Max
Unit
MHz
ns
80
tw(EXTCLKIN)H
tw(EXTCLKIN)L
viL(EXTCLKIN)
viH(EXTCLKIN)
6
6
ns
-0.3
2
0.8
V
High-level input voltage
VCCIO + 0.3
V
4.6.2 Clock Domains
4.6.2.1 Clock Domain Descriptions
The table below lists the device clock domains and their default clock sources. The table also shows the
system module control register that is used to select an available clock source for each clock domain.
Table 4-13. Clock Domain Descriptions
Clock Domain Name
Default Clock
Source
Clock Source
Selection Register
Description
HCLK
OSCIN
GHVSRC
•
•
Is disabled via the CDDISx registers bit 1
Used for all system modules including DMA, ESM
GCLK
OSCIN
GHVSRC
•
•
•
•
Always the same frequency as HCLK
In phase with HCLK
Is disabled separately from HCLK via the CDDISx registers bit 0
Can be divided by 1up to 8 when running CPU self-test (LBIST)
using the CLKDIV field of the STCCLKDIV register at address
0xFFFFE108
GCLK2
OSCIN
GHVSRC
•
•
•
•
Always the same frequency as GCLK
2 cycles delayed from GCLK
Is disabled along with GCLK
Gets divided by the same divider setting as that for GCLK when
running CPU self-test (LBIST)
VCLK
OSCIN
OSCIN
GHVSRC
GHVSRC
•
•
•
Divided down from HCLK
Can be HCLK/1, HCLK/2, ... or HCLK/16
Is disabled separately from HCLK via the CDDISx registers bit 2
VCLK2
•
•
•
•
Divided down from HCLK
Can be HCLK/1, HCLK/2, ... or HCLK/16
Frequency must be an integer multiple of VCLK frequency
Is disabled separately from HCLK via the CDDISx registers bit 3
VCLK3
VCLK4
OSCIN
OSCIN
GHVSRC
GHVSRC
•
•
•
Divided down from HCLK
Can be HCLK/1, HCLK/2, ... or HCLK/16
Is disabled separately from HCLK via the CDDISx registers bit 8
•
•
•
Divided down from HCLK
Can be HCLK/1, HCLK/2, ... or HCLK/16
Is disabled separately from HCLK via the CDDISx registers bit 9
VCLKA1
VCLKA2
VCLK
VCLK
VCLKASRC
VCLKASRC
•
•
Defaults to VCLK as the source
Is disabled via the CDDISx registers bit 4
•
•
Defaults to VCLK as the source
Is disabled via the CDDISx registers bit 5
66
