RM46L450
RM46L850
www.ti.com
SPNS184 –SEPTEMBER 2012
Table 5-5. ePWMx Switching Characteristics (continued)
PARAMETER
TEST CONDITIONS
MIN
MAX
UNIT
td(TZ-
Delay time, trip input active to PWM Hi-Z
20
ns
PWM)HZ
Table 5-6. ePWMx Trip-Zone Timing Requirements
PARAMETER
TEST CONDITIONS
Asynchronous
MIN
MAX
UNIT
cycles
cycles
cycles
tw(TZ)
Pulse duration, TZn input low
2 * TBePWMx
2 tc(VCLK4)
Synchronous
Synchronous, with input
filter
2 tc(VCLK4) + filter
width
