PCM9211
www.ti.com
SBAS495 –JUNE 2010
Register 62h, DIT Function Control 3/3
(Address: 62h, Write and Read)
DATA
Reg Name
Default Value
Memo
B7
RSV
0
B6
RSV
0
B5
TXDMUT
0
B4
RSV
0
B3
TXVFLG
0
B2
RSV
0
B1
RSV
0
B0
RSV
0
TXDMUT: DIT Output Audio Data Mute Control
0: No mute (default)
1: Audio data on biphase signal is Mute (zero data)
TXVFLG: DIT Output Validity Flag Control
0: V = '0', Valid (default)
1: V = '1', Invalid
Register 63h–68h, DIT Channel Status Data Buffer
(Address: 63h–68h, Write and Read)
DATA
Address
B7
B6
B5
B4
B3
B2
B1
B0
TXCS7
TXCS6
TXCS5
TXCS4
TXCS3
TXCS2
TXCS1
TXCS0
63h
CS Bit7
TXCS15
CS Bit15
TXCS23
CS Bit23
TXCS31
CS Bit31
TXCS39
CS Bit39
TXCS47
CS Bit47
CS Bit6
TXCS14
CS Bit14
TXCS22
CS Bit22
TXCS30
CS Bit30
TXCS38
CS Bit38
TXCS46
CS Bit46
CS Bit5
TXCS13
CS Bit13
TXCS21
CS Bit21
TXCS29
CS Bit29
TXCS37
CS Bit37
TXCS45
CS Bit45
CS Bit4
TXCS12
CS Bit12
TXCS20
CS Bit20
TXCS28
CS Bit28
TXCS36
CS Bit36
TXCS44
CS Bit44
CS Bit3
TXCS11
CS Bit11
TXCS19
CS Bit19
TXCS27
CS Bit27
TXCS35
CS Bit35
TXCS43
CS Bit43
CS Bit2
TXCS10
CS Bit10
TXCS18
CS Bit18
TXCS26
CS Bit26
TXCS34
CS Bit34
TXCS42
CS Bit42
CS Bit1
TXCS9
CS Bit0
TXCS8
64h
65h
66h
67h
68h
CS Bit9
TXCS17
CS Bit17
TXCS25
CS Bit25
TXCS33
CS Bit33
TXCS41
CS Bit41
CS Bit8
TXCS16
CS Bit16
TXCS24
CS Bit24X
TXCS32
CS Bit32
TXCS40
CS Bit40
TXCS0: Use of channel status block.
TXCS1: Linear PCM information.
TXCS2: Copyright information.
TXCS5 – TXCS3: Additional format information.
TXCS7 – TXCS6: Channel status mode.
TXCS15 – TXCS8: Category code.
TXCS19 – TXCS16: Source number.
TXCS23 – TXCS20: Channel number.
TXCS27 – TXCS24: Sampling frequency.
TXCS29 - TXCS28: Clock accuracy.
TXCS31 – TXCS30: Not defined.
TXCS32: Maximum audio sample word length.
TXCS35 – TXCS33: Sample word length.
TXCS39 – TXCS36: Original sampling frequency.
TXCS47 – TXCS40: Not defined.
The data in this register are used for both channels (L-ch and R-ch). When these register data are used for the
DIT channel status data, a channel status data of bit 48 or later is all '0'. All initial values of this register are all '0'.
