Register 6Dh, MPIO_B and Main Output Port Hi-Z Control
(Address: 6Dh, Write and Read)
DATA
Reg Name
Default Value
Memo
B7
MPB3HZ
0
B6
MPB2HZ
0
B5
MPB1HZ
0
B4
MPB0HZ
0
B3
SCKOHZ
0
B2
BCKHZ
0
B1
LRCKHZ
0
B0
DOUTHZ
0
MPB3HZ: MPIO_B3, Hi-Z Control
0: Defined by Group Function Assign register, 6Fh/MPBSEL. (default)
1: Hi-Z
MPB2HZ: MPIO_B2, Hi-Z Control
0: Defined by Group Function Assign register, 6Fh/MPBSEL. (default)
1: Hi-Z
MPB1HZ: MPIO_B1, Hi-Z Control
0: Defined by Group Function Assign register, 6Fh/MPBSEL. (default)
1: Hi-Z
MPB0HZ: MPIO_B0, Hi-Z Control
0: Defined by Group Function Assign register, 6Fh/MPBSEL. (default)
1: Hi-Z
SCKOHZ: Main Output Port, SCKO Hi-Z Control
0: Output (default)
1: Hi-Z
BCKHZ: Main Output Port, BCKO Hi-Z Control
0: Output (default)
1: Hi-Z
LRCKHZ: Main Output Port, LRCKO Hi-Z Control
0: Output (default)
1: Hi-Z
DOUTHZ: Main Output Port, DOUT Hi-Z Control
0: Output (default)
1: Hi-Z
