9.25 Smart Card Configuration 1 Register
BIOS or EEPROM configure system dependent Smart Card interface information through this register. Information
of this register can be read from the Smart Card configuration 1 alias register in the Smart Card global control register
set. The software utilizes this information and adjusts the software and firmware behavior if necessary.
Corresponding bits are tied to 0 if the socket is not implemented.
Class A and B support are depend on the system and integrated device. Supporting both classes requires method
(pins) to control 5.0 V and 3.0 V.
Default value and bit types are depending on the device. When this core is integrated into a device and does not have
all four sockets, removed sockets bits must be tied to 0 and changed to read-only bits.
See Table 9−15 for a complete description of the register contents. All bits in this register are reset by GRST only.
Bit
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
Name
Type
Default
Bit
Smart Card configuration 1
RW
0
RW
0
RW
0
RW
0
R
0
RW
0
RW
1
RW
1
R
0
7
RW
1
RW
1
RW
1
R
0
3
RW
1
RW
0
RW
0
15
14
13
12
11
10
9
8
6
5
4
2
1
0
Name
Type
Default
Smart Card configuration 1
R
0
RW
0
RW
1
RW
1
R
0
R
0
R
1
R
1
R
0
RW
0
RW
0
RW
0
R
0
RW
1
RW
1
RW
1
Register:
Offset:
Type:
Smart Card configuration 1
58h
Read/Write, Read-only (EEPROM, GRST only)
0374 3307h
Default:
9−15
