4.38 Card Control Register
The card control register is provided for PCI1130 compatibility. RI_OUT is enabled through this register, and the
enable bit is shared between functions 0 and 1. See Table 4−16 for a complete description of the register contents.
The RI_OUT signal is enabled through this register, and the enable bit is shared between functions 0 and 1.
Bit
7
6
5
4
3
2
1
0
Name
Type
Default
Card control
RW
0
RW
0
RW
0
R
0
R
0
RW
0
RW
0
RW
0
Register:
Offset:
Type:
Card control
91h
Read-only, Read/Write
00h
Default:
Table 4−16. Card Control Register Description
BIT
7 ‡§
6−3
SIGNAL
RIENB
RSVD
TYPE
RW
FUNCTION
Ring indicate enable. When this bit is 1, the RI_OUT output is enabled. This bit defaults to 0.
These bits are reserved. Do not change the value of these bits.
RW
CardBus audio-to-MFUNC. When this bit is set, the CAUDIO CardBus signal must be routed through an
MFUNC terminal. If this bit is set for both functions, then function 0 is routed.
2 ‡
AUD2MUX
RW
RW
0 = CAUDIO set to CAUDPWM on MFUNC terminal (default)
1 = CAUDIO is not routed.
When bit 1 is set, the SPKR terminal from the PC Card is enabled and is routed to tthe SPKROUT terminal.
The SPKR signal from socket 0 is XORed with the SPKR signal from socket 1 and sent to SPKROUT. The
SPKROUT terminal drives data only when the SPKROUTEN bit of either function is set. This bit is encoded
as:
1 ‡
SPKROUTEN
0 = SPKR to SPKROUT not enabled (default)
1 = SPKR to SPKROUT enabled
Interrupt flag. This bit is the interrupt flag for 16-bit I/O PC Cards and for CardBus cards. This bit is set when
a functional interrupt is signaled from a PC Card interface, and is socket dependent (i.e., not global). Write
back a 1 to clear this bit.
0 ‡
IFG
RW
0 = No PC Card functional interrupt detected (default)
1 = PC Card functional interrupt detected
‡
§
One or more bits in this register are cleared only by the assertion of GRST.
This bit is global in nature and must be accessed only through function 0.
4−27
