OMAP-L137 Low-Power Applications Processor
www.ti.com
SPRS563A–SEPTEMBER 2008–REVISED OCTOBER 2008
Table 6-39. McASP Registers Accessed Through Peripheral Configuration Port (continued)
Offset
McASP0
BYTE
McASP1
BYTE
McASP2
BYTE
Acronym
Register Description
ADDRESS
ADDRESS
ADDRESS
13Ch
140h
144h
148h
14Ch
150h
154h
158h
15Ch
0x01D0 013C
0x01D0 0140
0x01D0 0144
0x01D0 0148
0x01D0 014C
0x01D0 0150
0x01D0 0154
0x01D0 0158
0x01D0 015C
0x01D0 413C
0x01D0 4140
0x01D0 4144
0x01D0 4148
0x01D0 414C
0x01D0 4150
0x01D0 4154
0x01D0 4158
0x01D0 415C
0x01D0 813C DITUDRA3
0x01D0 8140 DITUDRA4
0x01D0 8144 DITUDRA5
0x01D0 8148 DITUDRB0
0x01D0 814C DITUDRB1
0x01D0 8150 DITUDRB2
0x01D0 8154 DITUDRB3
0x01D0 8158 DITUDRB4
0x01D0 815C DITUDRB5
Left (even TDM time slot) channel user data register
(DIT mode) 3
Left (even TDM time slot) channel user data register
(DIT mode) 4
Left (even TDM time slot) channel user data register
(DIT mode) 5
Right (odd TDM time slot) channel user data register
(DIT mode) 0
Right (odd TDM time slot) channel user data register
(DIT mode) 1
Right (odd TDM time slot) channel user data register
(DIT mode) 2
Right (odd TDM time slot) channel user data register
(DIT mode) 3
Right (odd TDM time slot) channel user data register
(DIT mode) 4
Right (odd TDM time slot) channel user data register
(DIT mode) 5
180h
184h
188h
18Ch
190h
194h
198h
19Ch
1A0h
1A4h
1A8h
1ACh
1B0h
1B4h
1B8h
1BCh
200h
204h
208h
20Ch
210h
214h
218h
21Ch
220h
224h
228h
22Ch
230h
234h
0x01D0 0180
0x01D0 0184
0x01D0 0188
0x01D0 018C
0x01D0 0190
0x01D0 0194
0x01D0 0198
0x01D0 019C
0x01D0 01A0
0x01D0 01A4
0x01D0 01A8
0x01D0 4180
0x01D0 4184
0x01D0 4188
0x01D0 418C
0x01D0 4190
0x01D0 4194
0x01D0 4198
0x01D0 419C
0x01D0 41A0
0x01D0 41A4
0x01D0 41A8
0x01D0 8180 SRCTL0
0x01D0 8184 SRCTL1
0x01D0 8188 SRCTL2
0x01D0 818C SRCTL3
0x01D0 8190 SRCTL4
0x01D0 8194 SRCTL5
0x01D0 8198 SRCTL6
0x01D0 819C SRCTL7
0x01D0 81A0 SRCTL8
0x01D0 81A4 SRCTL9
0x01D0 81A8 SRCTL10
Serializer control register 0
Serializer control register 1
Serializer control register 2
Serializer control register 3
Serializer control register 4
Serializer control register 5
Serializer control register 6
Serializer control register 7
Serializer control register 8
Serializer control register 9
Serializer control register 10
0x01D0 01AC 0x01D0 41AC 0x01D0 81AC SRCTL11
Serializer control register 11
0x01D0 01B0
0x01D0 01B4
0x01D0 01B8
0x01D0 41B0
0x01D0 41B4
0x01D0 41B8
0x01D0 81B0 SRCTL12
0x01D0 81B4 SRCTL13
0x01D0 81B8 SRCTL14
Serializer control register 12
Serializer control register 13
Serializer control register 14
0x01D0 01BC 0x01D0 41BC 0x01D0 81BC SRCTL15
Serializer control register 15
0x01D0 0200
0x01D0 0204
0x01D0 0208
0x01D0 020C
0x01D0 0210
0x01D0 0214
0x01D0 0218
0x01D0 021C
0x01D0 0220
0x01D0 0224
0x01D0 0228
0x01D0 022C
0x01D0 0230
0x01D0 0234
0x01D0 4200
0x01D0 4204
0x01D0 4208
0x01D0 420C
0x01D0 4210
0x01D0 4214
0x01D0 4218
0x01D0 421C
0x01D0 4220
0x01D0 4224
0x01D0 4228
0x01D0 422C
0x01D0 4230
0x01D0 4234
0x01D0 8200 XBUF0(1)
0x01D0 8204 XBUF1(1)
0x01D0 8208 XBUF2(1)
0x01D0 820C XBUF3(1)
0x01D0 8210 XBUF4(1)
0x01D0 8214 XBUF5(1)
0x01D0 8218 XBUF6(1)
0x01D0 821C XBUF7(1)
0x01D0 8220 XBUF8(1)
0x01D0 8224 XBUF9(1)
0x01D0 8228 XBUF10(1)
0x01D0 822C XBUF11(1)
0x01D0 8230 XBUF12(1)
0x01D0 8234 XBUF13(1)
Transmit buffer register for serializer 0
Transmit buffer register for serializer 1
Transmit buffer register for serializer 2
Transmit buffer register for serializer 3
Transmit buffer register for serializer 4
Transmit buffer register for serializer 5
Transmit buffer register for serializer 6
Transmit buffer register for serializer 7
Transmit buffer register for serializer 8
Transmit buffer register for serializer 9
Transmit buffer register for serializer 10
Transmit buffer register for serializer 11
Transmit buffer register for serializer 12
Transmit buffer register for serializer 13
(1) Writes to XRBUF originate from peripheral configuration port only when XBUSEL = 1 in XFMT.
Submit Documentation Feedback Peripheral Information and Electrical Specifications
133
