MSP430F530x, MSP430F5310
www.ti.com
SLAS677B –SEPTEMBER 2010–REVISED MARCH 2011
Electrical Characteristics
Active Mode Supply Current Into VCC Excluding External Current
(1) (2) (3)
over recommended operating free-air temperature (unless otherwise noted)
FREQUENCY (fDCO = fMCLK = fSMCLK
)
EXECUTION
MEMORY
PARAMETER
VCC
PMMCOREVx
1 MHz
8 MHz 12 MHz 20 MHz
25 MHz
UNIT
TYP MAX TYP MAX TYP MAX TYP MAX TYP MAX
0
1
2
3
0
1
2
3
0.25 0.27 1.55 1.68
0.28
0.30
0.32
1.74
1.91
2.09
2.58 2.78
2.84
IAM, Flash
Flash
RAM
3 V
mA
4.68 5.06
5.13
3.10
6.0
3.9
6.5
4.3
0.17 0.19 0.91 1.00
0.19
0.20
0.21
1.03
1.16
1.24
1.54 1.67
1.73
IAM, RAM
3 V
mA
2.84 3.11
3.1
1.87
(1) All inputs are tied to 0 V or to VCC. Outputs do not source or sink any current.
(2) The currents are characterized with a Micro Crystal MS1V-T1K crystal with a load capacitance of 12.5 pF. The internal and external load
capacitance are chosen to closely match the required 12.5 pF.
(3) Characterized with program executing typical data processing. LDO disabled (LDOEN = 0).
fACLK = 32786 Hz, fDCO = fMCLK = fSMCLK at specified frequency.
XTS = CPUOFF = SCG0 = SCG1 = OSCOFF= SMCLKOFF = 0.
