MSP430F530x, MSP430F5310
www.ti.com
SLAS677B –SEPTEMBER 2010–REVISED MARCH 2011
(1)
Schmitt-Trigger Inputs – General Purpose I/O
over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted)
PARAMETER
TEST CONDITIONS
VCC
1.8 V
3 V
MIN
0.80
1.50
0.45
0.75
0.3
TYP
MAX UNIT
1.40
V
VIT+
VIT–
Vhys
Positive-going input threshold voltage
2.10
1.8 V
3 V
1.00
V
Negative-going input threshold voltage
1.65
1.8 V
3 V
0.85
V
Input voltage hysteresis (VIT+ – VIT–
)
0.4
1.0
For pullup: VIN = VSS
For pulldown: VIN = VCC
RPull
CI
Pullup/pulldown resistor
Input capacitance
20
35
5
50
kΩ
VIN = VSS or VCC
pF
(1) Same parametrics apply to clock input pin when crystal bypass mode is used on XT1 (XIN) or XT2 (XT2IN).
(1)
Inputs – Ports P1 and P2
over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted)
PARAMETER
TEST CONDITIONS
VCC
MIN
MAX UNIT
Port P1, P2: P1.x to P2.x, External trigger pulse width to
set interrupt flag
(2)
t(int)
External interrupt timing
2.2 V/3 V
20
ns
(1) Some devices may contain additional ports with interrupts. See the block diagram and terminal function descriptions.
(2) An external signal sets the interrupt flag every time the minimum interrupt pulse width t(int) is met. It may be set by trigger signals shorter
than t(int)
.
Leakage Current – General Purpose I/O
over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted)
PARAMETER
TEST CONDITIONS
(1) (2)
VCC
MIN
MAX UNIT
±50 nA
Ilkg(Px.x)
High-impedance leakage current
1.8 V/3 V
(1) The leakage current is measured with VSS or VCC applied to the corresponding pin(s), unless otherwise noted.
(2) The leakage of the digital port pins is measured individually. The port pin is selected for input and the pullup/pulldown resistor is
disabled.
Outputs – General Purpose I/O (Full Drive Strength)
over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted)
PARAMETER
TEST CONDITIONS
VCC
MIN
CC – 0.25
CC – 0.60
CC – 0.25
CC – 0.60
MAX UNIT
(1)
I(OHmax) = –3 mA
V
V
V
V
VCC
1.8 V
(2)
I(OHmax) = –10 mA
VCC
VOH
High-level output voltage
V
(1)
I(OHmax) = –5 mA
VCC
3 V
1.8 V
3 V
(2)
I(OHmax) = –15 mA
VCC
(1)
I(OLmax) = 3 mA
VSS VSS + 0.25
(2)
I(OLmax) = 10 mA
VSS VSS + 0.60
VSS VSS + 0.25
VSS VSS + 0.60
Low-level output voltage
V
OL
(1)
I(OLmax) = 5 mA
I(OLmax) = 15 mA
(2)
(1) The maximum total current, I(OHmax) and I(OLmax), for all outputs combined should not exceed ±48 mA to hold the maximum voltage drop
specified.
(2) The maximum total current, I(OHmax) and I(OLmax), for all outputs combined should not exceed ±100 mA to hold the maximum voltage
drop specified.
Copyright © 2010–2011, Texas Instruments Incorporated
Submit Documentation Feedback
43
