Setting Charger Options
By writing ChargeOption() command (0x12H or 0b00010010), the IC allows users to change several charger
options after POR (Power On Reset) as shown in Table 3.
Table 3. Charge Options Register (0x12H)
BIT
BIT NAME
DESCRIPTION
[15]
ACOK Deglitch Time Adjust ACOK deglitch time.
Adjust
0: ACOK deglitch time 1.3s for bq24707, 1.2ms for bq24707A <default at POR>
1: ACOK deglitch time set to minimum (<50µs).
To change this option, VCC pin voltage must be above UVLO and ACDET pin voltage must be above
0.6V to enable IC SMBus communication and set this bit to 1 to disable the ACOK deglitch timer. After
POR the bit default value is 0 and ACOK deglitch time is 1.3s for bq24707 and 1.2ms for bq24707A.
[14:13] WATCHDOG Timer Set maximum delay between consecutive SMBus Write charge voltage or charge current command. The
Adjust
charge is suspended if the IC does not receive write charge voltage or write charge current command
within the watchdog time period and watchdog timer is enabled.
The charge is resumed after receive write charge voltage or write charge current command when
watchdog timer expires and charge suspends.
00: Disable Watchdog Timer
01: Enabled, 44 sec
10: Enabled, 88 sec
11: Enable Watchdog Timer (175s) <default at POR>
[12:11] Not In Use
11 at POR
[10]
EMI Switching
0: Reduce PWM switching frequency by 18% <default at POR>
Frequency Adjust
1: Increase PWM switching frequency by 18%
[9]
EMI Switching
0: Disable adjust PWM switching frequency <default at POR>
Frequency Enable
1: Enable adjust PWM switching frequency
[8:7]
IFAULT_HI
Short circuit protection high side MOSFET voltage drop comparator threshold.
Comparator
Threshold Adjust
00: 300mV
01: 500mV
10: 700mV <default at POR>
11: 900mV
[6]
[5]
Not In Use
0 at POR
IOUT Selection
0: IOUT is the 20x adapter current amplifier output <default at POR>
1: IOUT is the 20x charge current amplifier output
[4]
Comparator
0: 0.6V <default at POR>
Threshold Adjust
1: 2.4V
[3]
Not In Use
0 at POR
[2:1]
ACOC Threshold
Adjust
00: Disable ACOC
01: 1.33X of input current regulation limit
10: 1.66X of input current regulation limit <default at POR>
11: 2.22X of input current regulation limit
[0]
Charge Inhibit
0: Enable Charge <default at POR>
1: Inhibit Charge
Setting the Charge Current
To set the charge current, write a 16-bit ChargeCurrent() command (0x14H or 0b00010100) using the data
format listed in Table 4. With a 10mΩ sense resistor, the IC provides a charge current range of 128mA to
8.128A, with 64mA step resolution. Sending ChargeCurrent() below 128mA or above 8.128A clears the register
and terminates charging. Upon POR, charge current is 0A. A 0.1µF capacitor between SRP and SRN for
differential mode filtering, 0.1µF capacitor between SRN and ground for common mode filtering, and an optional
0.1µF capacitor between SRP and ground for common mode filtering is recommended. Meanwhile, the
capacitance on SRP should not be higher than 0.1µF in order to properly sense the voltage across SRP and
SRN for cycle-by-cycle under-current and over-current detection.
The SRP and SRN pins are used to sense RSR with a default value of 10mΩ. However, resistors of other values
