表8-20. CFG Register Field Descriptions (continued)
Bit
Field
Type
Reset
Description
6:4
CD_NUM[2:0]
CD_LEN[2:0]
CD_EN
R/W
000b
Number of current-detect exceeded thresholds selection
Number of current-detect exceeded thresholds to trigger a detection
000b = 1 (default)
001b = 2
010b = 4
011b = 8
100b = 16
101b = 32
110b = 64
111b = 128
3:1
R/W
000b
Current-detect measurement length selection
Current-detect measurement length in conversion periods
000b = 128 (default)
001b = 256
010b = 512
011b = 768
100b = 1280
101b = 1792
110b = 2560
111b = 3584
0
R/W
0b
Current-detect mode enable
0b = Disabled (default)
1b = Enabled
