8.6.30 REGMAP_CRC Register (Address = 3Eh) [reset = 0000h]
The REGMAP_CRC register is shown in 图8-55 and described in 表8-42.
Return to the Summary Table.
图8-55. REGMAP_CRC Register
15
14
13
12
11
10
2
9
1
8
0
REG_CRC[15:8]
R-00000000b
7
6
5
4
3
REG_CRC[7:0]
R-00000000b
表8-42. REGMAP_CRC Register Field Descriptions
Bit
15:0
Field
REG_CRC[15:0]
Type
Reset
Description
R
00000000
Register map CRC value
00000000b
8.6.31 RESERVED Register (Address = 3Fh) [reset = 0000h]
The RESERVED register is shown in 图8-56 and described in 表8-43.
Return to the Summary Table.
图8-56. RESERVED Register
15
14
13
12
11
10
2
9
1
8
0
RESERVED
R/W-00000000b
7
6
5
4
3
RESERVED
R/W-00000000b
表8-43. RESERVED Register Field Descriptions
Bit
15:0
Field
RESERVED
Type
Reset
Description
R/W
00000000
Reserved
00000000b Always write 0000000000000000b
