ADS1291
ADS1292
ADS1292R
www.ti.com
SBAS502A –DECEMBER 2011–REVISED MARCH 2012
Continuous Mode
Conversions begin when the START pin is taken high or when the START opcode command is sent. As seen in
Figure 38, the DRDY output goes high when conversions are started and goes low when data are ready.
Conversions continue indefinitely until the START pin is taken low or the STOP opcode command is transmitted.
When the START pin is pulled low or the stop command is issued, the conversion in progress is allowed to
complete. Figure 39 and Table 12 show the required DRDY timing to the START pin and the START and STOP
opcode commands when controlling conversions in this mode. To keep the converter running continuously, the
START pin can be permanently tied high. Note that when switching from pulse mode to continuous mode, the
START signal is pulsed or a STOP command must be issued, followed by a START command. This conversion
mode is ideal for applications that require a fixed continuous stream of conversions results.
START Pin
or
or
START(1)
Opcode
STOP(1)
Opcode
DIN
tDR
tSETTLE
DRDY
(1) START and STOP opcode commands take effect on the seventh SCLK falling edge.
Figure 38. Continuous Conversion Mode
tSDSU
DRDY and DOUT
tDSHD
START Pin
or
STOP(1)
STOP(1)
STOP Opcode
(1) START and STOP commands take effect on the seventh SCLK falling edge at the end of the opcode transmission.
Figure 39. START to DRDY Timing
Table 12. Timing Characteristics for Figure 39(1)
SYMBOL
DESCRIPTION
MIN
UNIT
START pin low or STOP opcode to DRDY setup time
to halt further conversions
tSDSU
8
tMOD
START pin low or STOP opcode to complete current
conversion
tDSHD
8
tMOD
(1) START and STOP commands take effect on the seventh SCLK falling edge at the end of the opcode transmission.
Copyright © 2011–2012, Texas Instruments Incorporated
Submit Documentation Feedback
31
Product Folder Link(s): ADS1291 ADS1292 ADS1292R
