Document Number: PS-MPU-6500A-01
Revision: 1.1
Release Date: 03/05/2014
MPU-6500 Product Specification
3.6 Absolute Maximum Ratings
Stress above those listed as “Absolute Maximum Ratings” may cause permanent damage to the device.
These are stress ratings only and functional operation of the device at these conditions is not implied.
Exposure to the absolute maximum ratings conditions for extended periods may affect device reliability.
Parameter
Rating
Supply Voltage, VDD
-0.5V to +4V
-0.5V to +4V
-0.5V to 2V
Supply Voltage, VDDIO
REGOUT
Input Voltage Level (AUX_DA, AD0, FSYNC, INT, SCL, SDA)
Acceleration (Any Axis, unpowered)
Operating Temperature Range
Storage Temperature Range
-0.5V to VDD + 0.5V
10,000g for 0.2ms
-40°C to +105°C
-40°C to +125°C
2kV (HBM);
250V (MM)
Electrostatic Discharge (ESD) Protection
Latch-up
JEDEC Class II (2),125°C, ±100mA
Table 9: Absolute Maximum Ratings
18 of 40
