ST92F124/F150/F250 - INTERRUPTS
Figure 54. Top Level Interrupt Structure
n
WATCHDOG ENABLE
WDGEN
CORE
RESET
TLIP
WATCHDOG TIMER
END OF COUNT
PENDING
MASK
TOP LEVEL
INTERRUPT
REQUEST
MUX
TLIS
OR
NMI
TLTEV
TLNM
TLI
VA00294
IEN
n
5.10 INTERRUPT RESPONSE TIME
cycles (DIVWS and MUL instructions) or 49 for
other instructions.
The interrupt arbitration protocol functions com-
pletely asynchronously from instruction flow and
requires 5 clock cycles. One more CPUCLK cycle
is required when an interrupt is acknowledged.
Requests are sampled every 5 CPUCLK cycles.
For a non-maskable Top Level interrupt, the re-
sponse time between a user event and the start of
the interrupt service routine can range from a min-
imum of 22 clock cycles to a maximum of 51 clock
cycles (DIV instruction), 49 clock cycles (DIVWS
and MUL instructions) or 45 for other instructions.
If the interrupt request comes from an external pin,
the trigger event must occur a minimum of one
INTCLK cycle before the sampling time.
In order to guarantee edge detection, input signals
must be kept low/high for a minimum of one
INTCLK cycle.
When an arbitration results in an interrupt request
being generated, the interrupt logic checks if the
current instruction (which could be at any stage of
execution) can be safely aborted; if this is the
case, instruction execution is terminated immedi-
ately and the interrupt request is serviced; if not,
the CPU waits until the current instruction is termi-
nated and then services the request. Instruction
execution can normally be aborted provided no
write operation has been performed.
An interrupt machine cycle requires a basic 18 in-
ternal clock cycles (CPUCLK), to which must be
added a further 2 clock cycles if the stack is in the
Register File. 2 more clock cycles must further be
added if the CSR is pushed (ENCSR =1).
The interrupt machine cycle duration forms part of
the two examples of interrupt response time previ-
ously quoted; it includes the time required to push
values on the stack, as well as interrupt vector
handling.
For an interrupt deriving from an external interrupt
channel, the response time between a user event
and the start of the interrupt service routine can
range from a minimum of 26 clock cycles to a max-
imum of 55 clock cycles (DIV instruction), 53 clock
In Wait for Interrupt mode, a further cycle is re-
quired as wake-up delay.
104/426
