PS/2 Model 30 Mode
7
6
5
4
3
2
1
0
INT
DRQ STEP TRK0 nHDSEL INDX
WP
nDIR
PENDING
F/F
RESET
COND.
0
0
0
N/A
1
N/A
N/A
1
BIT 0 DIRECTION
Active low status indicating the direction of head movement. A logic "0" indicates inward direction; a logic "1"
indicates outward direction.
BIT 1 WRITE PROTECT
Active high status of the WRITE PROTECT disk interface input. A logic "1" indicates that the disk is write protected.
BIT 2 INDEX
Active high status of the INDEX disk interface input.
BIT 3 HEAD SELECT
Active low status of the HDSEL disk interface input. A logic "0" selects side 1 and a logic "1" selects side 0.
BIT 4 TRACK 0
Active high status of the TRK0 disk interface input.
BIT 5 STEP
Active high status of the latched STEP disk interface output pin. This bit is latched with the STEP output going active,
and is cleared with a read from the DIR register, or with a hardware or software reset.
BIT 6 DMA REQUEST
Active high status of the DMA request pending.
BIT 7 INTERRUPT PENDING
Active high bit indicating the state of the Floppy Disk Interrupt.
STATUS REGISTER B (SRB)
Address 3F1 READ ONLY
This register is read-only and monitors the state of several disk interface pins in PS/2 and Model 30 modes. The
SRB can be accessed at any time when in PS/2 mode. In the PC/AT mode the data bus pins D0 - D7 are held in a
high impedance state for a read of address 3F1.
PS/2 Mode
7
1
6
1
5
4
3
2
1
0
DRIVE WDATA RDATA WGATE MOT
MOT
SEL0 TOGGLE TOGGLE
EN1
0
EN0
RESET
COND.
1
1
0
0
0
0
0
BIT 0 MOTOR ENABLE 0
Active high status of the MTR0 disk interface output pin. This bit is low after a hardware reset and unaffected by a
software reset.
BIT 1 MOTOR ENABLE 1
Active high status of the MTR1 disk interface output pin. This bit is low after a hardware reset and unaffected by a
software reset.
BIT 2 WRITE GATE
Active high status of the WGATE disk interface output.
SMSC DS – LPC47M14X
Page 28
Rev. 03/19/2001
