BIT 0 and 1 DRIVE SELECT
These two bits are binary encoded for the drive selects, thereby allowing only one drive to be selected at one time.
BIT 2 nRESET
A logic "0" written to this bit resets the Floppy disk controller. This reset will remain active until a logic "1" is written to
this bit. This software reset does not affect the DSR and CCR registers, nor does it affect the other bits of the DOR
register. The minimum reset duration required is 100ns, therefore toggling this bit by consecutive writes to this
register is a valid method of issuing a software reset.
BIT 3 DMAEN
PC/AT and Model 30 Mode:
Writing this bit to logic "1" will enable the DMA and interrupt functions. This bit being a logic "0" will disable the DMA
and interrupt functions. This bit is a logic "0" after a reset and in these modes.
PS/2 Mode: In this mode the DMA and interrupt functions are always enabled. During a reset, this bit will be cleared
to a logic "0".
BIT 4 MOTOR ENABLE 0
This bit controls the MTR0 disk interface output. A logic "1" in this bit will cause the output pin to go active.
BIT 5 MOTOR ENABLE 1
This bit controls the MTR1 disk interface output. A logic "1" in this bit will cause the output pin to go active.
DRIVE
DOR VALUE
1CH
0
1
2DH
BIT 6 MOTOR ENABLE 2
The MTR2 disk interface output is not supported in the LPC47M14x.
BIT 7 MOTOR ENABLE 3
The MTR3 disk interface output is not supported in the LPC47M14x.
TAPE DRIVE REGISTER (TDR)
Address 3F3 READ/WRITE
The Tape Drive Register (TDR) is included for 82077 software compatibility and allows the user to assign tape
support to a particular drive during initialization. Any future references to that drive automatically invokes tape
support. The TDR Tape Select bits TDR.[1:0] determine the tape drive number. Table 4 illustrates the Tape Select Bit
encoding. Note that drive 0 is the boot device and cannot be assigned tape support. The remaining Tape Drive
Register bits TDR.[7:2] are tristated when read. The TDR is unaffected by a software reset.
Table 4 – Tape Select Bits
TAPE SEL1
TAPE SEL0
DRIVE
(TDR.1)
(TDR.0)
SELECTED
0
0
1
1
0
1
0
1
None
1
2
3
Table 5 – Internal 2 Drive Decode - Normal
DRIVE SELECT OUTPUTS
MOTOR ON OUTPUTS
(ACTIVE LOW)
DIGITAL OUTPUT REGISTER
(ACTIVE LOW)
nDS1 nDS0
Bit 7 Bit 6 Bit 5 Bit 4 Bit1 Bit 0
nMTR1
nBIT 5
nBIT 5
nBIT 5
nBIT 5
nBIT 5
nMTR0
nBIT 4
nBIT 4
nBIT 4
nBIT 4
nBIT 4
X
X
X
1
X
X
1
X
1
X
X
0
1
X
X
X
0
0
0
1
1
X
0
1
0
1
X
1
0
1
1
1
0
1
1
1
1
X
0
0
SMSC DS – LPC47M14X
Page 30
Rev. 03/19/2001
