Legacy-Free Keyboard/Embedded Controller with SPI and LPC Docking Interface
Table 7.32 Wakeup Mask Register 7
N/A
HOST ADDRESS
8051 ADDRESS
POWER
0x7F65
VCC1
0x00
DEFAULT
BIT
D7
D6
D5
D4
D3
D2
D1
D0
-
-
-
-
-
-
-
-
HOST TYPE
8051 R/W
R
R
R/W
R
R
R
R/W
R/W
Reserved
SPIDONE
Reserved
FAN
FAN
BIT NAME
TACH2
TACH1
Note 7.36 When set ‘1’, a bit in this register masks the corresponding bit in Table 7.25, "Wakeup
Source Register 7".
Table 7.33 Wakeup Mask Register 8
N/A
HOST
ADDRESS
0x7F56
8051
ADDRESS
VCC1
0x00
POWER
DEFAULT
BIT
D7
D6
D5
D4
D3
D2
D1
D0
-
-
-
-
-
-
-
-
HOST
TYPE
R
R
R
R
R/W
R/W
R/W
R/W
8051 R/W
BIT NAME
Reserved
Reserved
Reserved
Reserved
LGPIO53
LGPIO52
LGPIO51
LGPIO50
Note 7.37 When set ‘1’, a bit in this register masks the corresponding bit in Table 7.26, "Wakeup
Source Register 8".
