15.1.1. Internal Oscillator Suspend Mode
When software writes a logic 1 to SUSPEND (OSCICN.5), the internal oscillator is suspended. If the sys-
tem clock is derived from the internal oscillator, the input clock to the peripheral or CIP-51 will be stopped
until one of the following events occur:
•
•
•
Port 0 Match Event.
Port 1 Match Event.
Comparator 0 enabled and output is logic 0.
When one of the internal oscillator awakening events occur, the internal oscillator, CIP-51, and affected
peripherals resume normal operation, regardless of whether the event also causes an interrupt. The CPU
resumes execution at the instruction following the write to SUSPEND.
