C8051F52x-53x
SFR Definition 15.2. OSCICL: Internal Oscillator Calibration
R
-
R/W
Bit6
R/W
Bit5
R/W
Bit4
R/W
OSCICL
Bit3
R/W
Bit2
R/W
Bit1
R/W
Reset Value
Varies
Bit7
Bit0
SFR Address:
0xB3
Bit7:
UNUSED. Read = 0. Write = don’t care.
Bits 6–0: OSCICL: Internal Oscillator Calibration Register.
This register determines the internal oscillator period. On C8051F52x/53x devices, the reset
value is factory calibrated to generate an internal oscillator frequency of 24.5 MHz.
SFR Definition 15.3. OSCIFIN: Internal Fine Oscillator Calibration
R/W
-
R/W
-
R/W
Bit5
R
R
R/W
Bit2
R/W
Bit1
R/W
Reset Value
undetermined
Bit Addressable
0xB0
OSCIFIN
Bit7
Bit6
Bit4
Bit3
Bit0
SFR Address:
Bit7–6: UNUSED. Read = 00b, Write = don't care.
Bit5–0: OSCIFIN. Internal oscillator fine adjustment bits. The valid range is between 0x00 and 0x27.
This register is a fine adjustment for the internal oscillator period. On C8051F52x/53x devices, the
reset value is factory calibrated to generate an internal oscillator frequency of 24.5 MHz.
136
Rev. 0.3
