C8051F52x-53x
SFR Definition 12.2. RSTSRC: Reset Source
R/W
—
R
R/W
R/W
R
R/W
R/W
R
Reset Value
FERROR C0RSEF SWRSF WDTRSF MCDRSF PORSF
PINRSF
Bit0
Variable
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
SFR Address:
0xEF
Note: Software should avoid read modify write instructions when writing values to RSTSRC.
Bit7:
Bit6:
UNUSED. Read = 1, Write = don't care.
FERROR: Flash Error Indicator.
0: Source of last reset was not a Flash read/write/erase error.
1: Source of last reset was a Flash read/write/erase error.
C0RSEF: Comparator0 Reset Enable and Flag.
0: Read: Source of last reset was not Comparator0.
Write: Comparator0 is not a reset source.
1: Read: Source of last reset was Comparator0.
Write: Comparator0 is a reset source (active-low).
SWRSF: Software Reset Force and Flag.
Bit5:
Bit4:
0: Read: Source of last reset was not a write to the SWRSF bit.
Write: No Effect.
1: Read: Source of last was a write to the SWRSF bit.
Write: Forces a system reset.
Bit3:
Bit2:
WDTRSF: Watchdog Timer Reset Flag.
0: Source of last reset was not a WDT timeout.
1: Source of last reset was a WDT timeout.
MCDRSF: Missing Clock Detector Flag.
0: Read: Source of last reset was not a Missing Clock Detector timeout.
Write: Missing Clock Detector disabled.
1: Read: Source of last reset was a Missing Clock Detector timeout.
Write: Missing Clock Detector enabled; triggers a reset if a missing clock condition is
detected.
Bit1:
PORSF: Power-On Reset Force and Flag.
This bit is set anytime a power-on reset occurs. Writing this bit enables/disables the V
DD
monitor as a reset source. Note: writing ‘1’ to this bit before the V monitor is enabled
DD
and stabilized may cause a system reset. See register VDDMON (SFR Definition 12.1)
0: Read: Last reset was not a power-on or V monitor reset.
DD
Write: V monitor is not a reset source.
DD
1: Read: Last reset was a power-on or V monitor reset; all other reset flags indeterminate.
DD
Write: V monitor is a reset source.
DD
Bit0:
PINRSF: HW Pin Reset Flag.
0: Source of last reset was not RST pin.
1: Source of last reset was RST pin.
104
Rev. 0.3
