OneNAND512Mb(KFG1216U2B-xIB6)
FLASH MEMORY
3.7.2.3 Programmable Burst Read Latency Operation
See Timing Diagrams 6.1 and 6.2
Upon power up, the number of initial clock cycles from Valid Address (AVD) to initial data defaults to four clocks.
The number of clock cycles (n) which are inserted after the clock which is latching the address. The host can read the first data with
the (n+1)th rising edge.
The number of total initial access cycles is programmable from three to seven cycles. After the number of programmed burst clock
cycles is reached, the rising edge of the next clock cycle triggers the next burst data.
Four Clock Burst Read Latency (BRWL=4 case)
Rising edge of the clock cycle following last read latency
triggers next burst data
CE
CLK
-1
0
1
2
3
4
AVD
tBA
Valid
Address
A0:
A15
DQ0:
DQ15
D6
D7
D0
D1
D2
D3
D7
D0
tIAA
tRDYS
OE
Hi-Z
Hi-Z
tRDYA
RDY
*Note: BRWL=4 is recommended for 40MHz~66MHz. Also, for frequency under 40MHz, BRWL can be reduced to 3.
3.7.3 Handshaking Operation
The handshaking feature allows the host system to simply monitor the RDY signal from the device to determine
when the initial word of burst data is ready to be read.
To set the number of initial cycles for optimal burst mode, the host should use the programmable burst read latency configuration (see
Section 2.8.19, "System Configuration1 Register").
The rising edge of RDY which is derived at one cycle prior of data fetch clock indicates the initial word of valid burst data.
3.7.4 Output Disable Mode Operation
When the CE or OE input is at VIH, output from the device is disabled.
The outputs are placed in the high impedance state.
