K9W4G08U1M
K9K2G08Q0M
K9K2G08U0M
K9W4G16U1M
K9K2G16Q0M
K9K2G16U0M
FLASH MEMORY
ABSOLUTE MAXIMUM RATINGS
Rating
K9K2GXXQ0M(1.8V) K9XXGXXUXM(3.3V)
Parameter
Symbol
Unit
V
VIN/OUT
VCC
-0.6 to + 2.45
-0.2 to + 2.45
-0.6 to + 4.6
-0.6 to + 4.6
Voltage on any pin relative to VSS
K9XXGXXXXM-XCB0
Temperature Under Bias
-10 to +125
-40 to +125
TBIAS
°C
K9XXGXXXXM-XIB0
K9XXGXXXXM-XCB0
Storage Temperature
TSTG
Ios
-65 to +150
5
°C
K9XXGXXXXM-XIB0
Short Circuit Current
mA
NOTE :
1. Minimum DC voltage is -0.6V on input/output pins. During transitions, this level may undershoot to -2.0V for periods <30ns.
Maximum DC voltage on input/output pins is VCC,+0.3V which, during transitions, may overshoot to VCC+2.0V for periods <20ns.
2. Permanent device damage may occur if ABSOLUTE MAXIMUM RATINGS are exceeded. Functional operation should be restricted to the conditions
as detailed in the operational sections of this data sheet. Exposure to absolute maximum rating conditions for extended periods may affect reliability.
RECOMMENDED OPERATING CONDITIONS
(Voltage reference to GND, K9XXGXXXXM-XCB0 :TA=0 to 70°C, K9XXGXXXXM-XIB0:TA=-40 to 85°C)
K9K2GXXQ0M(1.8V)
K9XXGXXUXM(3.3V)
Parameter
Symbol
Unit
Min
1.7
0
Typ.
1.8
0
Max
1.95
0
Min
2.7
0
Typ.
3.3
0
Max
3.6
0
Supply Voltage
Supply Voltage
VCC
VSS
V
V
DC AND OPERATING CHARACTERISTICS(Recommended operating conditions otherwise noted.)
K9K2GXXQ0M(1.8V)
K9XXGXXUXM(3.3V)
Unit
Parameter
Symbol
Test Conditions
Min
Typ
Max
Min Typ
Max
Page Read with
Serial Access
tRC=50ns, CE=VIL
IOUT=0mA
Operat-
ing
ICC1
-
10
20
-
15
30
Current Program
ICC2
ICC3
ISB1
-
-
-
-
10
10
-
20
20
1
-
-
-
15
15
-
30
30
1
mA
Erase
-
Stand-by Current(TTL)
CE=VIH, WP=PRE=0V/VCC
CE=VCC-0.2,
Stand-by Current(CMOS)
ISB2
-
20
100
-
20
100
WP=PRE=0V/VCC
µA
Input Leakage Current
Output Leakage Current
ILI
VIN=0 to Vcc(max)
-
-
-
-
±20
±20
-
-
-
-
±20
±20
ILO
VOUT=0 to Vcc(max)
VCC+
0.3
Input High Voltage
VIH*
VIL*
VOH
-
-
VCC-0.4
-0.3
-
-
-
2.0
-0.3
2.4
-
-
-
VCC+0.3
Input Low Voltage, All inputs
Output High Voltage Level
Output Low Voltage Level
0.4
0.8
-
V
K9K2GXXQ0M:IOH=-100µA
K9XXGXXUXM:IOH=-400µA
Vcc-0.1
-
K9K2GXXQ0M :IOL=100uA
K9XXGXXUXM :IOL=2.1mA
VOL
-
-
0.1
-
-
-
0.4
-
K9K2GXXQ0M :VOL=0.1V
K9XXGXXUXM :VOL=0.4V
Output Low Current(R/B)
IOL(R/B)
3
4
8
10
mA
NOTE : VIL can undershoot to -0.4V and VIH can overshoot to VCC +0.4V for durations of 20 ns or less.
12
