The K9K2GXXX0M is a 2112Mbit(2,214,592,512 bit) memory organized as 131,072 rows(pages) by 2112x8(X8 device) or
1056x16(X16 device) columns. Spare 64(X8) or 32(X16) columns are located from column address of 2048~2111(X8 device) or
1024~1055(X16 device). A 2112-byte(X8 device) or 1056-word(X16 device) data register and a 2112-byte(X8 device) or 1056-
word(X16 device) cache register are serially connected to each other. Those serially connected registers are connected to memory
cell arrays for accommodating data transfer between the I/O buffers and memory cells during page read and page program opera-
tions. The memory array is made up of 32 cells that are serially connected to form a NAND structure. Each of the 32 cells resides in a
different page. A block consists of two NAND structured strings. A NAND structure consists of 32 cells. Total 1081344 NAND cells
reside in a block. The program and read operations are executed on a page basis, while the erase operation is executed on a block
basis. The memory array consists of 2048 separately erasable 128K-byte(X8 device) or 64K-word(X16 device) blocks. It indicates
that the bit by bit erase operation is prohibited on the K9K2GXXX0M.
The K9K2GXXX0M has addresses multiplexed into 8 I/Os(X16 device case : lower 8 I/Os). This scheme dramatically reduces pin
counts and allows system upgrades to future densities by maintaining consistency in system board design. Command, address and
data are all written through I/O's by bringing WE to low while CE is low. Those are latched on the rising edge of WE. Command Latch
Enable(CLE) and Address Latch Enable(ALE) are used to multiplex command and address respectively, via the I/O pins. Some com-
mands require one bus cycle. For example, Reset Command, Status Read Command, etc require just one cycle bus. Some other
commands, like page read and block erase and page program, require two cycles: one cycle for setup and the other cycle for execu-
tion. The 256M byte(X8 device) or 128M word(X16 device) physical space requires 29(X8) or 28(X16) addresses, thereby requiring
four cycles for addressing: 2 cycles of column address, 3 cycles of row address, in that order. Page Read and Page Program need
the same four address cycles following the required command input. In Block Erase operation, however, only the two row address
cycles are used. Device operations are selected by writing specific commands into the command register. Table 1 defines the specific
commands of the K9K2GXXX0M.
The device provides cache program in a block. It is possible to write data into the cache registers while data stored in data registers
are being programmed into memory cells in cache program mode. The program performace may be dramatically improved by cache
program when there are lots of pages of data to be programmed.
The device embodies power-on auto-read feature which enables serial access of data of the 1st page without command and address
input after power-on.
In addition to the enhanced architecture and interface, the device incorporates copy-back program feature from one page to another
page without need for transporting the data to and from the external buffer memory. Since the time-consuming serial access and
data-input cycles are removed, system performance for solid-state disk application is significantly increased.
Table 1. Command Sets
Function
1st. Cycle
00h
2nd. Cycle
Acceptable Command during Busy
Read
30h
35h
-
Read for Copy Back
Read ID
00h
90h
Reset
FFh
80h
-
O
Page Program
Cache Program
Copy-Back Program
Block Erase
10h
15h
10h
D0h
-
80h
85h
60h
Random Data Input*
Random Data Output*
Read Status
85h
05h
E0h
70h
O
NOTE : 1. Random Data Input/Output can be executed in a page.
Caution : Any undefined command inputs are prohibited except for above command set of Table 1.
