3858 Group
Table 12 Electrical characteristics (3)
(VCC = 2.7 to 5.5 V, VSS = 0 V, Ta = –20 to 85 °C, unless otherwise noted)
Limits
Typ.
Symbol
ICC
Parameter
Unit
mA
Test conditions
Max.
8.0
Min.
High-speed mode
f(XIN) = 8 MHz
f(XCIN) = 32.768 kHz
Power source current
4.0
1.35
2.0
1.3
40
Output transistors “off”
High-speed mode
4.2
4.5
4.0
150
100
40
mA
mA
mA
µA
µA
µA
µA
µA
f(XIN) = 8 MHz (in WIT state)
f(XCIN) = 32.768 kHz
Output transistors “off”
Middle-speed mode
f(XIN) = 8 MHz
f(XCIN) = stopped
Output transistors “off”
Middle-speed mode
f(XIN) = 8 MHz (in WIT state)
f(XCIN) = stopped
Output transistors “off”
Low-speed mode
f(XIN) = stopped
f(XCIN) = 32.768 kHz
Output transistors “off”
Low-speed mode
30
f(XIN) = stopped
f(XCIN) = 32.768 kHz (in WIT state)
Output transistors “off”
Low-speed mode (VCC=3V)
f(XIN) = stopped
f(XCIN) = 32.768 kHz
Output transistors “off”
10
Low-speed mode (VCC=3V)
f(XIN) = stopped
f(XCIN) = 32.768 kHz (in WIT state)
Output transistors “off”
5.5
11
Increment when A/D conversion is executed
f(XIN) = 8 MHz
600
0.1
All oscillation stopped
(in STP state)
Ta=25 °C
Ta=85 °C
1.0
10
µA
µA
