VRS51L1050
Crystal consideration
The user should review the technical literature supplied
with the specific crystal or ceramic resonator or contact
the manufacturer to select the appropriate values for
external components.
The crystal connected to the VRS51L1050 oscillator
input should be of a parallel type, operating in
fundamental mode. The following table provides
suggested capacitor and resistor feedback values for
different operating frequencies:
XTAL1
Valid for VRS51L1050
XTAL
C1
C2
3MHz
30 pF
30 pF
-
6MHz
30 pF
30 pF
-
9MHz
30 pF
30 pF
-
12MHz
22 pF
22 pF
-
XTAL
VRS51L1050
R
XTAL
C1
C2
16MHz
30 pF
30 pF
-
25MHz
15 pF
15 pF
-
R
XTAL2
R
C1
C2
Note: Oscillator circuits may differ with different
crystals or ceramic resonators in higher oscillator
frequencies.
Crystals
or
ceramic
resonator
characteristics vary from one manufacturer to the
other.
