S/UNI®-ATLAS-3200 Telecom Standard Product Data Sheet
Preliminary
11.3 Microprocessor Cell Interface
Register 0x020: Microprocessor Cell Interface Control and Status
Bit
31:27
26
25
24
23
22
21
20
19
18
17
16
15:6
5
Type
Function
Unused
INSRDY
WRSOC
PHY[5]
PHY[4]
PHY[3]
PHY[2]
PHY[1]
PHY[0]
PROC_CELL
CRC10
INSRST
Unused
RSOC
Default
x
R
W
X
0
0
0
0
0
0
0
0
0
0
X
0
X
0
0
0
0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R
R
W
W
R/W
R/W
4
3
2
1
EXTCA
ABORT
RESTART
DMAREQINV
EXTRST
0
Bits [15 0] Cell Extraction
EXTRST
The EXTRST is used to reset the Microprocessor Extract Cell Interface. When EXTRST is
set to logic 0, the Extract FIFO operates normally. When EXTRST is logic 1, the extract
FIFO is immediately emptied and ignores writes. The extract FIFO remains empty and
continues to ignore writes until a logic 0 is written to EXTRST. While asserted, EXTRST
overrides all other bits affecting the Microprocessor Extract Cell Interface.
DMAREQINV
The DMAREQINV bit inverts the polarity of the UP_DMAREQ output. If DMAREQINV is
a logic 0, the UP_DMAREQ output is active high. If DMAREQINV is a logic 1, the
UP_DMAREQ output is active low.
