S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x061, 0x161, 0x261, 0x361, 0x461, 0x561, 0x661, 0x761:
RXCP Configuration 2
Bit
Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Function
Reserved
Reserved
IDLEPASS
Reserved
Reserved
Reserved
Reserved
Reserved
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
0
0
0
0
0
0
0
IDLEPASS:
The IDLEPASS bit controls the function of the Idle Cell filter. When IDLEPASS is written
with a logic zero, all cells that match the Idle Cell Header Pattern and Idle Cell Header
Mask are filtered out. When IDLEPASS is a logic one, the Idle Cell Header Pattern and
Mask registers are ignored. The default state of this bit and the bits in the Idle Cell Header
Mask and Idle Cell Header Pattern Registers enable the dropping of idle cells.
Reserved:
The reserved bits must be programmed to logic zero for proper operation.
Proprietary and Confidential to PMC-Sierra, Inc., and for its customers’ internal use.
Document No.: PMC- 2010299, Issue 2
220
