SDINV:
The signal detect input invert (SDINV) controls the polarity of the SD input. The value of
the SD input is logically XOR’ed with the value of the SDINV register. Therefore, when
SDINV is a logic zero, valid signal power is indicated by the SD input high. When SDINV
is a logic one, valid signal power is indicated by the SD input low.
