S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x058, 0x158, 0x258, 0x358, 0x458, 0x558, 0x658, 0x758:
DCRU Configuration
Bit
Type
R/W
Function
Reserved
Unused
Unused
Unused
Default
0
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
X
X
X
X
X
X
0
R
R
R
R/W
RUN
Reserved
Reserved
Reserved
Reserved:
The reserved bits must be programmed to zero for proper operation.
RUN:
The DLL lock status register bit RUN indicates the DCRU has found an initial delay line
lock. When the DCRU is attempting to recover the incoming serial stream, RUN is set
high. The RUN register bit is cleared only by a system reset or a software reset.
