PEX 8532 Port Register Configuration and Map
11.3
PEX 8532 Port Register Configuration and Map
The PEX 8532 port registers are configured similarly – not all the same. Port 0 of Station 0 and Port 8 of
Station 1 include more device-specific registers than the other station ports. The registers for these ports
contain setup and control information specific to the station. Also, Port 0 of Station 0 contains registers
used to set up and control the switch, and serial EEPROM interface logic and control.
The port register map is defined in Table 11-2. (Refer to Appendix A, “Serial EEPROM Memory Map,”
for a detailed description of this register map.)
Table 11-2. PEX 8532 Port Register Configuration and Map
Station 0,
Station 1,
Port 8
Station 0, Ports 1, 2, 3
Station 1, Ports 9, 10, 11
Register Types
Port 0
Configuration Header Registers
00h - 3Ch
40h - 44h
00h - 3Ch
40h - 44h
00h - 3Ch
40h - 44h
Power Management Capability Registers
Message Signaled Interrupt Capability Registers
PCI Express Capability Registers
Device Serial Number Extended Capability Registers
Power Budgeting Extended Capability Registers
Virtual Channel Extended Capability Registers
ECC Check Disable
48h - 64h
48h - 64h
48h - 64h
68h - 8Ch
68h - 8Ch
100h - 108h
138h - 144h
148h - 1C4h
1C8h
68h - 8Ch
100h - 108h
138h - 144h
148h - 1C4h
1C8h
100h - 108h
138h - 144h
148h - 1C4h
Device-Specific Error
1CCh - 1D0h
1D4h - 1DCh
1CCh - 1D0h
1D4h - 1D8h
Debug
1E0h - 1ECh,
1F8h - 1FCh
Power Management, Hot Plug, and Miscellaneous Control
1E0h - 1FCh
1E0h - 1ECh, 1F8h - 1FCh
Physical Layer (all except for Serial EEPROM-related)
Serial EEPROM
200h - 25Ch
260h - 264h
2C8h - 2F4h
308h - 31Ch
348h - 404h
660h - 73Ch
680h - 6ACh
6C0h - 71Ch
200h - 25Ch
Bus Number CAM Station 0, Station 1
I/O CAM Station 0, Station 1
2C8h - 2F4h
308h - 31Ch
348h - 404h
660h - 73Ch
680h - 6ACh
6C0h - 71Ch
AMCAM Memory Base and Limit
Ingress Control Registers
I/O CAM Upper Station 0, Station 1
Station 0 BAR, Station 1 BAR
740h - 79Ch
840h - 9ECh
740h - 79Ch
840h - 9ECh
Virtual Channel Station 0, Station 1
740h
Ingress Credit Handler (INCH) Registers
Ingress One-Bit ECC Error Count Register
9F0h - B7Ch
BE8h
9F0h- B7Ch
BE8h
A00h - B7Ch
Relaxed Completion Ordering (Ingress) Register –
Silicon Revisions BA/BB/BC Only
BECh
BECh
Relaxed Ordering Mode (Ingress) Register
BF0h - BFCh
C00h - C08h
FB4h - FFCh
BF0h - BFCh
C00h - C08h
FB4h - FFCh
Internal Credit Handler (ITCH) VC&T Threshold Registers
Advanced Error Reporting Capability Registers
FB4h - FFCh
