Port-to-Station Aggregation
8.2.2
Port-to-Station Aggregation
As previously stated, a single PEX 8532 PCI Express station is aggregated from multiple ports,
provided that the combined port width is less than or equal to 16 lanes. Figure 8-1 redraws the
PEX 8532 Transaction Layer architecture, by explicitly dividing a PCI Express station into individual
ingress and egress parts.
In a PCI Express source station, the write port to the ingress packet RAM is shared by up to four ingress
ports in a Time Domain Multiplex (TDM) manner. The wider the port, the more TDM slots are assigned
to that port. Within VOQs of a single source station, if multiple packets from different ingress ports are
available to be dispatched to the same destination, a Round-Robin arbiter controls which ingress port to
select next.
Moving to the internal fabric, the Read ports to ingress packet RAM and Write ports to egress packet
RAM are controlled by the PLX implementation of the CIOQ scheduling algorithm, where a unit in
scheduling is a station, rather than a port.
In a PCI Express destination station, the Read port to the egress packet RAM is shared by up to four
egress ports in a TDM manner as well. Furthermore, there are four independent egress schedulers.
Egress schedulers follow Virtual Channel arbitration, as required by the PCI Express Base r1.0a.
