Stereo audio codec with SPDIF interface
UDA1355H
MODE
FEATURES
SCHEMATIC
9
Data path:
• Input SPDIF to output I2S
• Input I2S to outputs DAC or SPDIF.
Features:
SPDIF LOCK
XTAL
PLL
MUTE
• Possibility to process input SPDIF, via
I2S-bus using an external DSP and
then to outputs DAC or SPDIF
DAC
SPDIF IN
• BCK and WS being master for both I2S
SPDIF OUT
input and output (different clocks)
2
I S INPUT
2
I S OUTPUT
• Input I2S to outputs DAC and SPDIF;
BCK and WS being master; clocks
based on crystal oscillator
2
2
I S slave
I S master
EXTERNAL DSP
(e.g. Sample Rate Convertor)
(SAA7715)
• Microcontroller mode:
– DAC sound features can be used
MGU845
– SPDIF output channel status bits
(two times 40) setting.
10
Data path:
• Input SPDIF to output DAC or I2S
• Input I2S-bus to output SPDIF.
Features:
• Possibility to process input SPDIF, via
I2S-bus using an external DSP and
then to output SPDIF
SPDIF LOCK
XTAL
PLL
MUTE
DAC
• Input SPDIF to outputs I2S and DAC;
locking onto the SPDIF input signal;
BCK and WS being master
• Input I2S to output SPDIF; BCK and
WS being master; clocks are
SPDIF IN
SPDIF OUT
2
I S INPUT
2
I S OUTPUT
generated by the crystal oscillator
2
2
I S slave
I S master
• Microcontroller mode:
EXTERNAL DSP
(e.g. Sample Rate Convertor)
(SAA7715)
– DAC sound features can be used
– SPDIF input channel status bits
(two times 40) can be read
MGU846
– SPDIF output channel status bits
(two times 40) setting.
11
12
13
14
15
Not used
See microcontroller mode
See microcontroller mode
See microcontroller mode
Not used
