PCF8574; PCF8574A
NXP Semiconductors
Remote 8-bit I/O expander for I2C-bus with interrupt
Table 5.
Pin connectivity
A2 A1 A0 A6 A5 A4 A3 A2 A1 A0 R/W
PCF8574A address map
Address of PCF8574A
Address byte value
7-bit
hexadecimal
address
Write
Read
without R/W
VSS VSS VSS
VSS VSS VDD
VSS VDD VSS
VSS VDD VDD
VDD VSS VSS
VDD VSS VDD
VDD VDD VSS
VDD VDD VDD
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
-
-
-
-
-
-
-
-
70h
72h
74h
76h
78h
7Ah
7Ch
7Eh
71h
73h
75h
77h
79h
7Bh
7Dh
7Fh
38h
39h
3Ah
3Bh
3Ch
3Dh
3Eh
3Fh
8. I/O programming
8.1 Quasi-bidirectional I/Os
A quasi-bidirectional I/O is an input or output port without using a direction control register.
Whenever the master reads the register, the value returned to master depends on the
actual voltage or status of the pin. At power on, all the ports are HIGH with a weak 100 A
internal pull-up to VDD, but can be driven LOW by an internal transistor, or an external
signal. The I/O ports are entirely independent of each other, but each I/O octal is
controlled by the same read or write data byte.
Advantages of the quasi-bidirectional I/O over totem pole I/O include:
• Better for driving LEDs since the p-channel (transistor to VDD) is small, which saves
die size and therefore cost. LED drive only requires an internal transistor to ground,
while the LED is connected to VDD through a current-limiting resistor. Totem pole I/O
have both n-channel and p-channel transistors, which allow solid HIGH and LOW
output levels without a pull-up resistor — good for logic levels.
• Simpler architecture — only a single register and the I/O can be both input and output
at the same time. Totem pole I/O have a direction register that specifies the port pin
direction and it is always in that configuration unless the direction is explicitly
changed.
• Does not require a command byte. The simplicity of one register (no need for the
pointer register or, technically, the command byte) is an advantage in some
embedded systems where every byte counts because of memory or bandwidth
limitations.
